Heavy Duty Rubber Oil Suction and Delivery Hose Tank Truck Hose Manufacturer

Heavy Duty Rubber Oil Suction and Delivery Hose Tank Truck Hose

Request a Quote

View All: http://zebungmarinehose.com/2-4-3-heavy-duty-oil-suction-and-delivery-hose.html

Designed with copper wire, the heavy duty oil suction and delivery hose is characterized by antistatic electricity and good resistance to vacuum. Suitable for connecting with tank trucks, this heavy duty oil hose is widely used for delivering various petroleum products with aromatic content higher than 50%.

Construction
Tube: NBR
Reinforcement: High tensile textile cord with helix steel wire
Cover rubber: NBR CR
Safety factor: 3:1

Temperature Range
-40℃~80℃

Standard Compliance
HT/T2540-93

Technical Parameters

I.D		O.D	W.P		B.P.		Weight	Length
mm	inch	mm	psi	bar	psi	bar	kg/m	ft	m
51	2"	65	150	10	450	30	2.01	200	61
64	2-1/2"	80	150	10	450	30	3.02	200	61
76	3"	92	150	10	450	30	3.51	200	61
102	4"	120	150	10	450	30	5.17	200	61
127	5"	147	150	10	450	30	7.63	200	61
152	6"	172	150	10	450	30	9.01	200	61

Note: Specifications can be made upon request.
