Tank Truck Hose
Tank truck hoses are crucial for safely transporting petroleum products in industrial environments. Available in 150/250/500psi options, these hoses endure demanding conditions.
The 250 psi heavy-duty hose is designed for tank trucks, handling petroleum products with up to 50% aromatic content. The 150 psi hose sets industry standards, ideal for in-plant and oil field loading, offering strength and flexibility for gasoline and oil transport. Rubber hoses for tank trucks are essential in petroleum, chemical, and metallurgical industries, ensuring secure oil transportation. Opting for high-quality hoses is vital for safe and stable oil delivery.
Basic Information- Inner tube: NR (tensile strength ≥12MPa)
- Reinforcement: Textile cord wrapping helical steel wire copper wire
- Outer cover: NR (tensile trength ≥10MPa)
- Appearance: Smooth or corrugated
- Working temperature: -30°C to 120°C
- Safety factor: 3:1
- Color: Available in various colors such as black, red, etc.
Features
The hose features a robust construction, with both the inner and outer layers crafted from oil-resistant nitrile rubber, offering exceptional durability and longevity. Its high bond strength between layers prevents delamination, ensuring the hose remains intact even under demanding conditions. Additionally, its enhanced abrasion resistance provides added durability, effectively prolonging its lifespan. Overall, this hose is designed to withstand the rigors of various applications, making it a reliable choice for industries requiring dependable performance.
| Item Code | Inner Diameter | Outer Diameter | Working Pressure | Burst Pressure | Weight | Max. Length | |||
| mm | inch | mm | bar | psi | bar | psi | kg/m | m | |
| TTOSD051-150 | 51 | 2" | 64.4 | 10 | 150 | 30 | 450 | 1.91 | 61 |
| TTOSD064-150 | 64 | 2-1/2" | 78.4 | 10 | 150 | 30 | 450 | 2.48 | 61 |
| TTOSD076-150 | 76 | 3" | 90.8 | 10 | 150 | 30 | 450 | 3.00 | 61 |
| TTOSD089-150 | 89 | 3-1/2" | 106.2 | 10 | 150 | 30 | 450 | 4.33 | 61 |
| TTOSD102-150 | 102 | 4" | 119.2 | 10 | 150 | 30 | 450 | 4.90 | 61 |
| TTOSD051-300 | 51 | 2" | 66.8 | 20 | 300 | 60 | 900 | 2.29 | 61 |
| TTOSD064-300 | 64 | 2-1/2" | 81.2 | 20 | 300 | 60 | 900 | 2.95 | 61 |
| TTOSD076-300 | 76 | 3" | 94 | 20 | 300 | 60 | 900 | 3.63 | 61 |
| TTOSD089-300 | 89 | 3-1/2" | 107.8 | 20 | 300 | 60 | 900 | 4.58 | 61 |
| TTOSD102-300 | 102 | 4" | 120.8 | 20 | 300 | 60 | 900 | 5.18 | 61 |
Note: specifications, pressures, colors and other parameters can be customized according to customers' requirements.
