The U5D electric furniture actuator is a miniature version of the , and is specifically designed for use in electric sofas and massage chairs. It is a slipper type linear actuator, and produces very little noise during operation, and takes up very little space. This linear actuator is often installed in electric sofa pillows where the required load capacity is small.
Appearance and size Curve graph ① Load VS Curent; ② Current (A); ③ Load (N); ④ Load VS Speed; ⑤ Speed (mm/s)
Code of Parameters| code | Rated laod（N） | Rated current（A） | Rated speed (mm/s) | ||
| Push | Pull | No-load(32VDC) | Full-load(24VDC) | ||
| Short motor (3800RPM) | |||||
| A | 2000 | 1500 | 1.5 | 9.3 | 5.2 |
| B | 1000 | 1000 | 1.5 | 26.4 | 10.8 |
| Long motor(3400RPM) | |||||
| E | 2500 | 2000 | 2..8 | 9.3 | 5.2 |
| F | 2000 | 2000 | 3 | 13.2 | 6.9 |
| G | 1500 | 1500 | 4 | 26.4 | 10.8 |
1=12V
2=24V(standard)1=straight
2=coiled
1=0/180°
2=45°
3=90°
4=135°1=slot 6.2mm, hole Φ6.4mm
2=slot 6.2mm, hole Φ8mm
3=slot 6.2mm, hole Φ10mm(standard)
4=slot 6.2mm, hole Φ10mm,tube Φ8mm
1=0.5m
2=1m
3=1.5m
4=2m
5=3m
6=0.35m
7=0.75m
8=0.8m
9=0.25m1=Tined leads
2=01pin(standard)
3=Din 6pin
4=Y cable，01pin male, Din 5pin female(0.5m)
5=V cable，01pin male, Din 5pin female(0.35m)
6=Din 5pin
7=2pin VH-3.96MM
8=110 terminal
9=E cable, 01pin male，01pin female，5pin female
A=Three trailers，01pin male，01pin female×2，5pin female
1=no(standard)
2=single Hall sensor
3=Dual Hall sensor
