5-Shaft Cling Film Rewinder (with Perforation)
Request a Quote
Model: PPD-CFPL300
Master roll: diameter ≤400mm, width 300mm
Unwinding paper core diameter: 76mm
Rewinding paper core diameter: 30/38mm or customized
Finished roll width: 300mm
Max. film length: 150m
Distance between perforations: 200-400mm
Machine speed: 600m/min
Voltage: 220/380/415V
Applications
5-shaft cling film rewinder is mainly used for converting a master roll of cling film into several rolls of smaller diameter. With the servo motor, the machine will cross perforate the film to the preset pitch distance during rewinding process. Automatic labeling unit is configured.
- 5 shaft rewinding, high production efficiency;
- PLC HMI Inverter control, easy to set film length of finished roll, provide improved flatness of film roll;
- Machine alarms and automatically stops when no paper core;
- Servo motor control for perforation, length of perforated line is adjustable;
- Automatic labeling with high precision;
