HP-250X Flow Pack Wrapping Machine

HP-250X Flow Pack Wrapping Machine
HP-250X Flow Pack Wrapping Machine
HP-250X Flow Pack Wrapping Machine
HP-250X Flow Pack Wrapping Machine
HP-250X Flow Pack Wrapping Machine
HP-250X Flow Pack Wrapping Machine
HP-250X Flow Pack Wrapping Machine
HP-250X Flow Pack Wrapping Machine
HP-250X Flow Pack Wrapping Machine
Request a Quote

Samples

Specifications of Flow Pack Wrapping Machine
Model HP-250X
Name Flow pack packaging machine
Bag width 30-110mm (max. width: 250mm)
Bag length 65-190mm 120-280mm
Voltage 220V, 50/60HZ
Power 2.4KW
Film material Heat seal film
Weight Approx. 500 kg
Products contacting part 304 stainless steel
Dimensions (L×W×H) 3770×670×1450 mm
Application Stationery industry

Features
1. The flow pack wrapping machine is controlled by a double transducer and the bag length can be freely adjusted, with no test run and film waste. A lot of time and film is thus saved.
2. Parameters are easy to set on the human-computer interface.
3. Self-detection function ensures malfunctions and faults are clearly shown on the touchscreen.
4. With the combination of a photoelectric sensor and digital cutting system, the film sealing and cutting is of high accuracy.
5. The temperature is controlled by PID in order to suit different packaging materials.
6. The positioning system is sensitive and quick, with no film sticking or film waste.
7. The drive system has a compact structure and provides reliable performance and convenient maintenance.
8. Functional software is used for flow wrapper machine control, simplifying function adjustment and technic upgrade.
9. Discharging device can be chosen according to customer’s requirements. For example, the discharging can be performed depending on the pencil color.
