Planetary Gearmotor

Request a Quote

View All: http://motors-shanbo.com/3-1-planetary-gearmotor.html

Planetary gearbox is a type of gearbox where the input and output shafts are aligned, it is employed to transmit the largest torque in the most compact form, known as torque density, particularly useful for large loads applications. The planetary gearbox can be combined with different brushed and brushless DC motors. Shanbo EM can offer custom-specific planetary gearmotor solutions by assembling various motors and planetary gearboxes.

Motor Selection Range

Gear ratios: 3-864:1
Torque: 600Nm

Protection class: IP67
Operating temperature: -40°C – 70°C

Specifications

EM64ZYX05

Voltage: 24V DC
Torque: 1.8N.m
Speed: 500RPM

Power: 94W
Current: 7.5A

Working Duty: S2
Protection Class: IP54

Voltage: 36V DC
Torque: 1.3N.m
Speed: 470RPM

Power: 64W
Current: 10A

Working Duty: S2
Protection Class: IP54

EM42ZYX14

Voltage: 24V DC
Torque: 20N.m
Speed: 5RPM

Power: 10.5W
Current: 2A
Working Duty: S2

Protection Class: IP44
Insulation Class: 504:1

EM42ZYX03

Voltage: 12V DC
Torque: 5.6N.m
Speed: 30RPM

Power: 18W
Current: 4A

Working Duty: S2
Insulation Class: 56:1

Voltage: 24V DC
Torque: 70N.m
Speed: 8RPM

Power: 58W
Current: 6A

Working Duty: S2
Protection Class: IP54

EM78ZYX01

Voltage: 24 DC
Torque: 300N.m
Speed: 1.5RPM

Power: 47W
Current: ≤6.4A
Working Duty: S1

Protection Class: IP65
Insulation Class: 768:1

EM78ZYX02

Voltage: 28 DC
Torque: 200N.m
Speed: 1.5RPM

Power: 32W
Current: ≤3A
Working Duty: S1

Protection Class: IP65
Insulation Class: 768:1

EM78ZYX03

Voltage: 28 DC
Torque: 300N.m
Speed: 0.875RPM

Power: 28W
Current: ≤3.2A
Working Duty: S1

Protection Class: IP65
Insulation Class: 768:1

EM80ZYX03

Voltage: 24V DC
Torque: 120 N.m
Speed: 9.8±10%RPM

Power: 125W
Current: 10A
Working Duty: S2

Protection Class: IP65
Insulation Class: 144:1

EM80ZYX04

Voltage: 48V DC
Torque: 170N.m
Speed: 10RPM

Power: 180W
Current: 6.5A
Working Duty: S2

Protection Class: IP65
Insulation Class: 144:1

Voltage: AC220V
Torque: 150N.m
Speed: 8RPM

Power: 125W
Current: 4.5A

Working Duty: S2
Protection Class: IP55

EM84ZYX01

Voltage: 12V DC
Torque: 8N.m
Speed: 400RPM

Power: 330W
Current: 45A
Working Duty: S2

Protection Class: IP43
Insulation Class: 6.75:1

Voltage: AC380V
Torque: 100N.m
Speed: 88RPM

Power: 920 W
Current: 2.6A

Working Duty: S2
Protection Class: IP55

EM112ZYX01

Voltage: 26 DC
Torque: 53N.m
Speed: 55RPM

Power: 300W
Current: ≤23A
Working Duty: S3

Protection Class: IP54
Insulation Class: 46:1
