WFQ-1000V/1300V Computerized Slitting Machine
Applications
The WFQ-1000V/1300V computerized slitting machine is applicable for roll materials, such as BOPP, PET, CPP, CPE, PVC, aluminium foil, paper, among others. The automatic slitting equipment is generally employed for trimming and slitting based on actual user demand.
Features of Computerized Slitting Machine
1. The roll paper slitting machine adopts variable frequency speed control system.
2. Controlled by magnetic powder clutch, the rewinding of the material is completed through inflatable axis.
3. An automatic waste material collecting device is available with this computer-controlled slitter.
4. Apart from material metering, the computerized slitting machine has the function of automatic shutdown.
5. The control cabinet with the function of input and output display is controlled by computer, resulting in easy maintenance of the product.
6. Device with circular cutting knife is optional.
Model | 1000 | 1300 |
Max Diameter of Paper Roll | 600mm | 600mm |
Max. Width of Roll Paper | 1000mm | 1300mm |
Inner Dia. of Roll Paper | 76mm | 76mm |
Slitting Size | 20-1000mm | 20-1300mm |
Slitting Capacity | 160m/min | 160m/min |
Deviation Correction Accuracy | ±1mm | ±1mm |
Power | 3.8kW | 4.8kW |
Machine Weight | 1500kg | 1650kg |
Overall Dimensions | 2200×1300×1500 | 2450×1300×1500 |
