Application
The industrial screw conveyor is designed to transport powder, granular and horizontal block materials at less than 20° inclination. The conveyor is widely used in the processing of building materials, electricity, chemical, metallurgy, coal, aluminum magnesium, machinery, light industry, grain and food. However, industrial screw conveyor cannot work for perishable, viscous, and easily caked materials because they are bonded to the screw and moving or plugging at the suspension bearing while rotating can cause system failure.

Applicable materials
Cement, coal powder, grain, fertilizer, ash, sand, dust, etc.

Remarks: material temperature < 200 ℃

Parameters

Model	200	250	315	400	500
Pitch	200	250	315	355	400
n	100	90	80	71	63
Q	13	22	31	62	98
n	80	71	63	56	50
Q	10	18	24	49	78
n	63	56	50	45	40
Q	8	14	19	39	62
n	50	45	40	36	32
Q	6.2	11	15.4	31	50

Remarks:
1. n – Rotation speed (r/min) (±10%)
2. Q – Conveying capacity (m³/h)

Features

High conveying efficiency, safe and reliable work, simple structure.
Good dust-proof sealing and a cleaning device in the discharging end.
Low noise when working.
