Filter Regulator Unit (FR Unit)
Request a Quote
AW Series 2-in-1 air preparation unit combining air filter and pressure regulator in one to ensure clean air in a pneumatic system
- Compressed Air Treatment Unit/Air Preparation Unit
- Port Size: 1/4"–1"
- Filtration Accuracy: 40µm (5µm, 1µm optional)
- Working Temperature: 5℃ to 60℃
Features
- Integrated design combining air filtration and regulation
- Pressure adjustment knob with locking screw for precise and tamper-proof control
- Equipped with a standard ring-typed pressure gauge, which is clear and easy to read
- The filtered water is collected in the cup, and the metal housing protects it from physical impact
- Equipped with an aluminum cup guard to resist external pressure impact
- Optional manual or automatic drainage configuration
- Filter precision is available in 1μm, 5μm, and 40μm levels
- Designed with a compact structure for easy installation and use
- Push-in automatic locking structure preventing deviation caused by external interference
- Low pressure loss and high water separation efficiency
Specifications
| Category | |
| Operating pressure | 0-1.0MPa |
| Filtration accuracy | 40µm (5µm, 1µm optional) |
| Working temperature | 5℃ to 60℃ |
| Port size | 1/4"–1" |
