This product has been discontinued and removed from our shelves.

The JBG-40F/E rebar threading machine is used to roll right-handed threads or left-handed threads on rebar with a maximum thread length of 300mm. The threaded rebar can then be connected with a coupler or used as removable form tie in reinforced concrete for tension-force-counteracting purposes. The JBG 40F/E is especially suitable for threading on rebar grades of HRB 335, HRB400, and HRB 500 with a diameter range of φ14- φ40mm.

Functions
  • Right-handed thread rolling
  • Left-handed thread rolling
  • Rib-stripping on rebar
Advantages
  • Simultaneous rib-stripping and thread rolling enhance productivity and save labor.
  • The rebar threading machine has a compact structure, making it easier for transportation and occupies less space.
  • Manual adjustment to the clamp tightens the processing rebar.
  • The cooling system uses a water soluble coolant, which has a better performance than oil cooling.
Technical Parameters
Suitable For Rebar Diameter 14mm-40mm.
MAX Thread Length 300mm
Roller Thread Angle 60°/ 75°
Roller Thread Pitch(mm) (customizable) UNC or metric or BSW
Rated Power 5.5KW
Electrics (customizable) 3-380V-50Hz, 3-440V-60Hz, 3-220V-60Hz
Rotated Speed 49r/min
Dimension(L*W*H) 1400*720*1030mm
G/W 450kg
