Vacuum drying oven can perform routine drying and aging test up to 200 ° C. This oven offers efficient heating and uniform temperatures through forced convection and an air jacket design. The vacuum drying oven Simplewell designed can achieve a temperature deviation of ±2.0℃ (100℃) or higher. Intelligent control system enables the economical and energy-efficient operation of the oven.
This drying oven is suitable for the quality inspection, material screening, aging and drying of electronics, electrical appliances, communication, instruments, vehicles, battery packs, medical, and aerospace to name a few.

Reference Standards

GB/T29251-2012 Vacuum ovens
JB/T9505 Vacuum drying chamber

Specifications

Model		SVD-023	SVD-049	SVD-115
Internal dimensions (L)
W	mm/inch	285/11.22	385/15.16	500/19.69
H	mm/inch	285/11.22	385/15.16	500/19.69
D	mm/inch	295/11.61	330/15.16	460/18.11
External dimensions (including the handle)
W	mm/inch	515/20.27	621/24.45	730/28.74
H	mm/inch	660/25.98	770/30.32	880/34.65
D	mm/inch	660/25.98	690/27.17	820/32.28
Input power (KW)		1KW	1.5KW	2KW
Power supply (V)	AC220V 50HZ
Temp. range	RT 15℃-200℃
Vacuum degree	atmospheric pressure-1KPa
Stability	± 0.5℃
Pressure relief	From atmospheric pressure to -15KPa ≤30min
Heating rate	RT 15℃-150℃, around 1℃/min
Recovery	≤10min
Noise	≤60DB

Features

A fuzzy adaptive PID control method, enabling more accurate control under different working conditions
Small temperature deviation and good uniformity. Heated air is fully mixed by a fan to produce forced air circulation inside the chamber, ensuring an even temperature distribution.
USB interface for easy data recording
Cloud control (mobile and device linkage)
A set of independent settable over temperature protector; and the controller also has a set of temperature protector independent of the control channel sensor; dual protection to ensure the safety of the test product
