Mobile Rehabilitation van with air conditioned facilities

1.	Truck Chassis Brand Name	KAMA
2.	Engine valve	8
3.	Engine Overhead Cam	DOHC
3.	Engine Overhead Cam	4.	Ground Clearance	200 mm
5.	Manufacturing Year	2014
6.	Make/Model: (a) Engine Model (b) Chassis Model (c) Model Code (d) Color	Make/Model: (a) 4108 KMC1124P3 (b) KMC1124P3 (c) Off white
7	Steering system	Power steering
8	Engine Power	88KW/2800RPM
9	Engine Capacity	4214 CC
10	Number of Cylinders	4 (Four)
11	Number of Valves and Valve Arrangement	4, in line
12	Seating Capacity	3
13	Overall length	8000mm (without container)
14	Overall width	2330mm
15	Overall height	2550mm
16	Wheel base	4500mm
17	Gross vehicle weight (KG)	12320 kg
18	Fuel system (EFI\MPI\ECI)	MPI
19	Suspension System Front	1124P leaf spring
20	Suspension System Rear	1080P3 leaf spring
21	Brake System Front	Air Brake
22	Brake System Rear	Air Brake
23	Fuel Tank Capacity	100 Liters
24	Fuel type	Diesel
25	Tire Size and Brand	7.50-16, LUHE
26	Transmission system	6T46ISUZU TEC
27	Ground Clearance	210 mm

Mobile rehabilitation vans are required to be customized with the following equipment (other equipment or facilities)

1.	Container (including fabrication and fitments)	1. Complete re-locatable box ISO container(20ft x 7.4ft x 8ft); divided into two parts: a therapy room and registration/ audio –visual room 2. Thermo insulated walls ensure an even temperature distribution. 3. Concealed air draft ducted air conditioning, in both compartments. 4. Hot compressed polyurethane paneled walls with an interconnecting locking arrangement (greater than 40 mm- the insulation barrier will be 60 mm sides and 60 mm top and floor) 5. Extendable Teflon coated PVC top with retractable aluminum section structure with one rear flap door (fitted with Hydraulic Wheel chair Lift) and one side door mounted on hinges with Teflon bushes 6. Panels that consist of both inner and outer lining with the inner lining coated in aluminum powder at a 1.2 mm thickness with an intervening rigid foam core, stuck with adhesive. 7. Corrosion free container and the floor with 18 mm Plywood should be covered with an antistatic PVC sheet, fitted with solar panels and linked with a solar inventor.
	Container (including fabrication and fitments)	1. Space for necessary openings for door and windows on the side walls should be ensured during the building of the body, therapy and other audio visual equipment, air conditioning and fitment for electrical opening etc. 2. Work station (Registration Desk) and a desk for a couple of patients waiting for their therapy session. 3. File cabinet and cabinet for therapy instruments and other tools 4. AC\DC sockets in the location are necessary. 5. Generator compartment should be outfitted with a silent generator or solar inverter\lights for general lighting. 6. Complete fitments of all electrical and water connections for the equipment. 7. Parts and materials used in container bottom floor shall not exceed ISO corners. 8. The container’s bottom floor shall have appropriate strength and structure, to allow the container to be installed, fixed onto a truck chassis and trailer, and de-installation from truck chassis and trailer. It should comply with ISO 1161 and ISO 1496 standards.
	Solar panel linked with solar inverter	Solar panel linked with solar inverter: Specifications: 1. Load: 180w 2. Operating time: 2 hour 3. Solar panel capacity: 250 w and 2 (two) pieces 4. Battery capacity: 12v/200 Ah 5. Charge controller: 300w/25A 6. Inverter: 12v/250w
2.	Hydraulic Wheel Chair Lift	1. Maximum lifting load: 350 KG 2. Maximum lifting height: 700-1400 mm (might vary depending on the height of the container) 3. Voltage: 12/24 V 4. Length and width of platform: 1220x751 mm
3.	Water tank and external duct	Water storage tanks with minimum of a 50 liter capacity as well as external supply ducts.
4.	Wash stand with mirror, soap and towel hanger	As per standard specifications. Small scrub stations with running water dispensed out of SS tanks must be provided.
5.	Air conditioning unit	Ceiling mounted 2- ton system
6.	Shelves with revolving chair and droppable table	Built into the container shelves with a revolving chair and a droppable table
7.	At least six multi pin plug outlets	At least Six multi pin plugs should be built into the container.
8.	MS stepper for Door Opening means:	MS stepper for Door Opening means a metal steel made stepper (stair case) is used at the door steps to provide easy accesses. Dimension: 50x40x46 cms
9.	Fire Extinguisher	CO2 with standard specification refills (3 liter capacity)
10.	Wall mounted file and instrument cabinets	Built into the container
11.	Wall mounted working cabinets	Built into the container. (1 m height, 1 length)
12.	Working Chair	Working chair built into the container
13.	Working Table with Drawer	Working table with a drawer is built into the container
14.	Display board for offered services	1. Easily detachable display board- can be used both inside as well and outside the van for public information 2. Mounted on the walls of registration/audio visual room; 3. Display board size (Feet): 3 X 2
15.	Towel holder	Towel holder as per standard specifications.
16.	Wall mirror	Wall mirror as per standard specifications.
