Applications
Our vertical cream filling machine is customized to meet specific customer requirements, and is suitable for filling a variety of thick, creamy materials such as lipsticks, oils, syrups, shampoos and more. The filling capacity varies from 5-5000ml and the velocity is up to 45 bottles per minute.
Parameter
CZJ 5 vertical cream filling machine| Filling volume | Pressure | Velocity | Precision |
| 5-60ml | 0-45 bot/min | 0.2-0.6 Mpa | ≤±1% |
| Filling volume | Pressure | Velocity | Precision |
| 10-120ml | 0-35 bot/min | 0.2-0.6 Mpa | ≤±1% |
| Filling volume | Pressure | Velocity | Precision |
| 25-250ml | 0-30 bot/min | 0.2-0.6 Mpa | ≤±1% |
| Filling volume | Pressure | Velocity | Precision |
| 50-500ml | 0-30 bot/min | 0.2-0.6 Mpa | ≤±1% |
| Filling volume | Pressure | Velocity | Precision |
| 100-1000ml | 0-25 bot/min | 0.2-0.6 Mpa | ≤±1% |
| Filling volume | Pressure | Velocity | Precision |
| 250-2500ml | 0-18 bot/min | 0.2-0.6 Mpa | ≤±1% |
| Filling volume | Pressure | Velocity | Precision |
| 500-5000ml | 0-12 bot/min | 0.2-0.6 Mpa | ≤±1% |
Characteristics
1. The piston and cylinder in the filling machine are made of 316L stainless steel and tetrafluoroethylene.
2. The pneumatic filling machine is controlled using a compressed gas drive, making it a suitable choice for use in environments with a high explosion prevention standards and high humidity without sacrificing safety.
3. High precision: The machine is equipped with start control, counter and mechanical positioning, therefore, it features an excellent precision and can be expertly controlled. Data is displayed on an easy to read screen.
4. In case of emergency stop, just press the emergency switch and the piston will automatically resume its initial position and stop filling.
5. According to actual needs, it can freely switch from the "manual" to "automatic" filling state.
We specialize in the production of equipment for the manufacturing of cream, lipstick, perfume, nail polish and powders.
Cream filling machine
Lipstick filling machine
Perfume filling machine
Nail polish filling machine
Yuxiang as a leading vertical cream filling machine manufacturer and supplier, mainly provides cream filling equipment for cosmetics manufacturing, chemical manufacturing and pharmaceutical manufacturing plant. Our company offer complete shampoo and cream process line including mixing, agitating, dispensing, homogenizing, filling and sealing as well as custom solutions. For the different types of materials like lotion, cream, ointment products, our filling machines can be designed and configured in customer needs.
