Collaborative Robot Palletizer, RP-10

Collaborative Robot Palletizer, RP-10
Collaborative Robot Palletizer, RP-10
Collaborative Robot Palletizer, RP-10
Collaborative Robot Palletizer, RP-10
Request a Quote

With the largest pallet (1200mmx1200mm), the height of stacked goods can reach 1650 mm. The height may be affected by case size and claw model. The claw can lift goods as heavy as 20 kg.

  • Output: 8 cases/min

Packaging Style

Examples

Specifications

Maximum palletized load height 2100mm (including pallet height); Generally up to 1650mm (including pallet height)
Maximum working payload 20kg
Maximum working speed 8 cases/minute
Working Radius of Robotic Arm 1600mm
Safety function 16 certified PL=d cell level safety functions by ISO13849-1
Teach Pendant 10.1 inch capacitive display, emergency stop button and three-way switch, 3-meter cable, 2 USB connectors
IP ratings Robotic manipulator arm: IP54, teach pendant: IP65 Grippers and other accessories: IP32
Interface Inputs and outputs of multiple safety functions, including emergency stop, safety protection, cooperation mode
Software Offline editing and 3D simulation: TMstudio Palletizing Wizard
Setting and execution: TM Palletizing Operator software package
Indicator light Indicator light remains red while power on, and indicator light turns off while power off.
