VB26C City Bus Air Conditioner
Request a Quote
Features
- Roof-mount layout makes convenient opening and overhauling. Compact design, make it perfect to equip the CNG city buses.
- Fashionable appearance, perfectly integrating with the blue body;
- High quality fiberglass epoxy resin case and cover, high in strength and resistance to vibration and corrosion.
- Abundant and substantial cooling capacity, low noisy, low power consumption.
- World-brand key parts assure the system's reliability and stability.
- Water -proof connectors efficiently increase the system's reliability and electric parts' lifespan.
- Universal parts' application leads maintaining interchangeability, mostly lowing down after-sales service costs.
- Applying buses: 9-10m city bus, especially for CNG city bus.
Model | | |
Standard Cooling Capacity | 26000Kcal/h | |
Max Cooling Capacity | 28000 Kcal/h | |
Refrigerant | HFCR134a | |
Compressor | Model | 4NFCY |
Displacement | 647cc | |
Evaporator | Type | Copper Tube & Aluminium Fins |
Blower Type | Double Axle Centrifugal Flow | |
Blower Quantity | 6 | |
Blower Output | 6000 m3/h | |
Condenser | Type | Copper Tube & Aluminium Fins |
Fan Type | Axial Flow | |
Fan Quantity | 4 | |
Fan Output | 8000 m3/h | |
Control System | Bus Interior Temperature | 16℃-27℃ Adjustable |
Defrosting Protection | 2℃ | |
High Pressure Protection | 2.5Mpa | |
Low Pressure Protection | 0.05Mpa | |
External Dimension | 2595×1900×250mm | |
Total current | ≤100A(24V) | |
Applying Buses | 9-10m City Bus, 10m Intercity Bus |
Note: One year (12 months) warranty period since the date the products have been installed.
VehiClima Industry is a China city bus air conditioner manufacturer. In addition to bus air conditioner, we also offer recreational vehicle air conditioner, truck air conditioner, military vehicle air conditioner, engineering vehicle air conditioner, and more.
