Spray Dryer

Request a Quote

View All: http://plastic-process.com/4-5-cylinder-vacuum-spraying-drying-equipment.html

Applications
The spray dryer is used to continuously dry viscous powder, liquid and solid particles. It can dry anywhere between 3000-1500kg of material per hour.

Parameter

Grade	VDD03-25	VDD05-33	VDD10-40	VDD15-30
Capacity (kg/h )	300	500	1000	1500
Diameter (mm)	Ø600	Ø800	Ø1000	Ø1300
Inlet Height (mm)	2500	3300	4000	5300
Outlet Height (mm)	500	500	500	500
Resistant Time (min)	3-30	5-40	6-50	8-60
Heating Area (m2)	7.6	18	35	70
Vibration Power (Kw)	0.75*2	1.1*2	1.7*2	4.5*2
Heating Temp. (℃ )	Max. 160	Max. 160	Max. 160	Max. 160
Heating Power (Kw)	20	35	55	85
Spray Pressure (bar)	10-50	10-50	10-50	10-50
Vacuum (Mpa)	-0.08	-0.08	-0.08	-0.08

Operational Principle
The continuous cylinder vacuum dryer has an additional spraying function: liquid materials can be sprayed into the vacuum drying system under high pressure, with the water from these materials quickly evaporating. The initially dried viscous powder is vibrated and conveyed along a helical conveyance path. After they are fully dried, they will be discharged through the bottom vacuum hopper.

Features

It can dry continuously.
The material retention time is the same as that of heating time, which ensures a high drying efficiency during the drying process.
The heating area increases and the drying efficiency is high because of the disc design.
Its integrated design with no mechanical seal parts can maintain an ideal vacuum for a long time and low energy consumption.
