Silicon Carbide Heat Exchanger, Standard Type

Request a Quote

View All: http://glasslined-equip.com/5-1-silicon-carbide-heat-exchanger.html

SiC Heat Exchanger

This standard type silicon carbide heat exchanger is a shell and tube heat exchanger made with corrosion-resistant tube plates and silicon carbide (SiC) tubes, making it an ideal solution for various applications such as heating, cooling and condensation processes involving highly corrosive chemicals. With its advanced material and robust construction, our SiC shell and tube heat exchanger can provide optimal corrosion resistance performance and long service life for the chemical and pharmaceutical industries.

Typical Applications

Bromine, Sulfuric Acid, Hydrofluoric Acid, Nitric Acid, Hydrochloric Acid, etc.;

Alkalis;

Halogenated Compounds;

Salt Solutions;

Organic Compounds;

Technical Data

Each tube is subjected to test at pressure of 185 Bar before installation;
Shell diameter range: DN100 to DN600;
Standard length of tube: 1000 to 3000mm;
Heat exchange area: 1 to 60m2;
Tube diameter: 14mm, 19mm;
Horizontal or vertical installation;
Temperature range: -19°C to 100°C;
Pressure range: -0.1MPa to 0.3MPa;
CE, ATEX, FDA compliant

Comparison Chart of Thermal Conductivity

We can use double-tube plates design to separate process fluid from working fluid so that the two fluids will not be mingled even the O-ring breaks.

Silicon carbide corrosion performance
Testing Environment Conc. Reagent	Corrosive Weight Loss		(mg/cm²yr)
(Wt%)	Temperature (C)	Pressureless-sintered Silicon Carbide No Free SiC)	Reaction-bonded Silicon Carbide 12% SiC)
98% H2SO4	100	1.8	55
50% NaOH	100	2.6	>1000
53% HF	25	< 0.2	7.9
85% H3PO4	100	< 0.2	8.8
70% HNO3	100	< 0.2	0.5
45% KOH	100	< 0.2	>1000
25% HCI	70	< 0.2	0.9
10% HF plus 57% HNO3	25	< 0.2	>1000
Qianqiao produces every SiC heat exchanger with pressureless-sintered silicon carbide**
