Spindle Shaper
Request a Quote
Spindle shaper is particularly used to cut various size grooves, rebates and joints, as well as processing flat or curved surfaces.
Specifications
Spindle Shaper, MX5116Y
| Max. working thickness | 120mm |
| Spindle diameter | Φ35mm |
| Spindle speed | 6000/8000/10000rpm/min |
| Power | 4kw/5.5kw |
| Sliding table length | 1100mm |
| Travel of sliding table | 870mm |
| Working table size | 1080*680mm |
| Dimension | 1700*700*1100mm |
Spindle Shaper, MX5117B-2
| Max. working thickness | 120mm |
| Spindle diameter | Φ35mm |
| Spindle speed | 6000/8000/10000rpm/min |
| Power | 4kw/5.5kw |
| Sliding table length | / |
| Travel of sliding table | / |
| Working table size | / |
| Dimension | 1130*670*1020mm |
| Spindle rotation | Clockwise/Counterclockwise |
| Machine weight | 350kg |
Spindle Shaper, M5118B
| Max. working thickness | 120mm |
| Spindle diameter | Φ35mm |
| Spindle speed | 6000/8000/10000rpm/min |
| Power | 5.5kw/7.5kw |
| Sliding table length | / |
| Travel of sliding table | / |
| Working table size | / |
| Dimension | 1200*800*1020mm |
| Spindle rotation | / |
| Machine weight | 450kg |
Spindle Shaper, MX5117B-1
| Max. working thickness | 120mm |
| Spindle diameter | Φ35mm |
| Spindle speed | 6000/8000/10000rpm/min |
| Power | 4kw/5.5kw |
| Sliding table length | / |
| Travel of sliding table | / |
| Working table size | / |
| Dimension | 1130*670*1020mm |
| Spindle rotation | Counterclockwise |
| Machine weight | 350kg |
Spindle Shaper, MX5317
| Max. working thickness | 120mm |
| Spindle diameter | Φ35mm |
| Spindle speed | 6000/8000/10000rpm/min |
| Power | 4kw×2 |
| Sliding table length | / |
| Travel of sliding table | / |
| Working table size | / |
| Dimension | 1800*700*1020mm |
| Spindle rotation | / |
| Machine weight | 550kg |
Spindle Shaper, MX53110
| Max. working thickness | 120mm |
| Spindle diameter | Φ35mm |
| Spindle speed | 8000/10000rpm/min |
| Power | 5.5/7.5kw×2 |
| Sliding table length | / |
| Travel of sliding table | / |
| Working table size | / |
| Dimension | 1200*1000*1020mm |
| Spindle rotation | / |
| Machine weight | 850kg |
