Telecom Power Cable Type II
Telecom power cable Type II has a conductor of stranded tinned copper wires per ASTM B172, a separator tape and limited smoke, non-halogen polyolefin insulation.
Telecom power cable Type II can be used at 600 volts, 105°C dry, 75℃ wet.
Telecom power cable Type II is for use in central offices, telecom power systems (batteries and rectifiers), transmission and remote control systems. It is suitable for both fixed and mobile installations. Custom telecom power cable can be made upon request according to different performance requirements.
Our telecom power cable Type II meets UL 44, UL 66 and UL 758 standards. It has passed the following mechanical and electrical tests: FT4-ST1 vertical-tray flame test and smoke release test, VW-1 vertical flame test, FT2 horizontal flame test, aging test on insulation materials, dielectric voltage withstand test, etc.
| Part Number | Conductor Size | Stranding | Insulation Thickness(mm) | Complete Cable Diameter (mm) |
| Type II | 18AWG | 7/0.40 | 0.76 | 3.0 |
| Type II | 16AWG | 7/0.50 | 0.76 | 3.3 |
| Type II | 14AWG | 41/0.254 | 1.14 | 4.9 |
| Type II | 12AWG | 65/0.254 | 1.14 | 5.3 |
| Type II | 10AWG | 105/0.254 | 1.14 | 6.1 |
| Type II | 8AWG | 41/0.50 | 1.52 | 7.4 |
| Type II | 6AWG | 65/0.50 | 1.52 | 8.4 |
| Type II | 4AWG | 105/0.50 | 1.52 | 10.3 |
| Type II | 2AWG | 165/0.50 | 1.52 | 11.6 |
| Type II | 1/0AWG | 266/0.50 | 2.03 | 14.9 |
| Type II | 2/0AWG | 342/0.50 | 2.03 | 16.3 |
| Type II | 4/0AWG | 532/0.50 | 2.03 | 19.3 |
| Type II | 350AWG | 882/0.50 | 2.41 | 24.8 |
| Type II | 500AWG | 1221/0.50 | 2.41 | 28.3 |
| Type II | 750AWG | 1850/0.50 | 2.79 | 33.9 |
