Request a Quote

Packing Sample Pictures

Technical Parameters
Model HP-6PC HP-8PC HP-10PC
Mechanical workstation 6 8 10
Packaging materials Laminated film, PE, PP, etc. Laminated film, PE, PP, etc. Laminated film, PE, PP, etc.
Pouch types Stand up (with or without zipper), flat bag (3/4 side seal bag, hand bag, zippered bag), paper bag, etc. Stand up (with or without zipper), flat bag (3/4 side seal bag, hand bag, zippered bag), paper bag, etc. Stand up (with or without zipper), flat bag (3/4 side seal bag, hand bag, zippered bag), paper bag, etc.
Pouch size W: 100-300mm L: 100-400mm W: 100-240mm L: 100-300mm W: 100-200mm L: 100-300mm
Packaging speed 30-60 bags/min (depending on film and material weight) 30-60 bags/min (depending on film and material weight) 50-80 bags/min (depending on film and material weight)
Machine weight 1000KG 1200KG 1400KG
Power supply Three-phase 380V 50HZ/60HZ Three-phase 380V 50HZ/60HZ Three-phase 380V 50HZ/60HZ
Total power 2KW 2KW 3.5KW
Compressed air consumption 0.6m³/min (or customized) 0.6m³/min (or customized) 0.6m³/min (or customized)
Dimensions 1550 (L)×1350 (W) ×1400(H) mm 1550 (L)×1350 (W)×1400 (H) mm 2145 (L) ×1750 (W) ×1550 (H) mm


Features
1. Automatic Production

The granule pouch filling sealing machine replaces traditional manual packaging, realizes mass production and greatly decreases cost.

2. Food Hygiene Standard
When manufacturing this premade pouch packaging machine, all contact surfaces and components apply hygienic material to ensure a high food safety level.

3. Good Quality Pouch
Pre-made pouches used have nice pattern and good seal quality.

4. Wide Packaging Material Range
Applicable packaging materials include laminated film, single-layer PE, PP film, paper, etc.

5. Wide Applications
This type of automatic pouch sealing machine is appropriate for granule products, such as pet food, cereal, nut, seed, just to name a few.

6. User-Friendly Control System
For electric control system, the granule pouch filling sealing machine makes use of Mitsubishi PLC, color touchscreen and human-computer interface. It's convenient to operate. The variable frequency motor allows flexible speed which can be adjusted according to actual manufacture demands.

7. Machine Detection
Automatic inspecting system detects many process related procedures and parameters, such as air pressure, temperature, bag feeding, filling, sealing quality, machine state and coding. By doing so, packaging material and raw material can be saved.
