Premade Pouch Granule Packaging Machine
Vertical Form Fill Seal Machines for Granular Products
- Stations
- 8
- Bags Per Hour
- 1800-3300
- Bag Length
- Up to 450mm
- Bag Width
- 220-350mm
This packaging solution is versatile and well-suited for a wide range of products. It handles chunky items such as tofu, fish snacks, eggs, candies, dates, cereals, chocolates, biscuits, and peanuts with ease. Additionally, it excels in packaging granular products like crystalline monosodium glutamate, granular medicines, seeds, chemical materials, sugar, seasoning powders, sunflower seeds, nuts, and animal feed.
- Whole grains
- Frozen food
- Pet food
- Biscuits
- Dried fruit
- Candy
- Hardware
- Plastic parts
- Date Coding Machine
- PLC Control System
- Bag Opening Device
- Vibration Device
- Pneumatic Cylinder
- Solenoid Valve
- Temperature Control
- Vacuum Pump
- Frequency Converter
- Conveying System
- Effortless Adjustment: Quickly switch packaging bag specifications with one-touch width adjustments for maximum convenience.
- Efficient and Reliable Design: Single-axis drive with an internal cam ensures fast packaging speeds, stable operation, simplified maintenance, and reduced defect rates.
- Advanced Heating Module: Modular heating system with precise temperature control and fault alert notifications.
- User-Friendly Operation: Integrated PLC POD (touchscreen) control system offers an intuitive interface, making operation simple and hassle-free.
- Versatile Applications: Compatible with a wide range of materials, including liquids, pastes, granules, powders, and solids. Easily adapt to different products by switching to the appropriate dosing device.
Tailored for your granular product packaging needs, the equipment accommodates pre-made bag sizes ranging from 220–350mm in width and up to 450mm in length, providing flexibility for various packaging requirements. With operating speeds of 30–55 bags per minute, you can easily adjust the feeding speed to suit your production demands. This efficient system ensures your production rhythm stays optimized while delivering consistent and reliable packaging performance to meet your goals.
Kinds of Pouches: 3-side, four edge-sealing bag, self-reliance bag, handbag, spout bags, zipper bag, compound bag, etc
| Model | |
| Number of Stations | 8 stations |
| Working Process | Bag Feeding → Date Coding → Zipper Bag Opening (depending on actual needs) → Bag Opening → Pouch Filling → Heat Sealing 1 →Heat Sealing 2 |
| Bag Type | Pre-made Pouches |
| Bag Length | Max.450mm |
| Bag Width | 220-350mm |
| Packaging Speed | 1800-3300bags/hour (depending on feeding speed) |
| Total Power | 7kW |
| Machine Weight | 1.8t |
| Machine Dimensions (L×W×H) | 1620×1840×1700mm |
| Compressed Air Consumption | 1.2m³/min (compressed air is supplied by user) |
