F107A Iron and Manganese Removal Device

F107A Iron and Manganese Removal Device
Request a Quote

The F107A iron and manganese removal equipment forms manganese greensand filters with an automatic backwash for iron reduction collected with the F67C3 valve. It removes iron and manganese from the water, which makes it applicable to underwater cleaning in areas with a high rate of iron and manganese, such as industrial softening and RO pre-treatment.

Features:

1. Equipped with an exhaust port.
2. Features a port connecting liquid level system to control pumps.

Parameters
Model F107A
Inlet/outlet 1 "F
Drain 1"F
Mounting base 2.5" -8NPSM
Riser pipe 1.05"OD
Flow rate 4m³/h
Filter tank 6"--14"
Water pressure 0.15-0.6Mpa
Water temperature 5-25℃
Water turbidity <15NTU
pH valve 6.8~9
Ambient temperature 5-50℃
Application

50m³/h iron and manganese removal devices applied in school
Because iron and manganese seriously exceed the standard, it is easy to scale, so ordinary valves are easy to damage. Our ceramic sealing ball valves are used to prevent this.
