AAC Packaging Machine

Request a Quote

View All: http://aac-equipment.com/6-2-aac-packaging-machine.html

Packed Finished Products

The AAC packaging machine will pack AAC blocks or panels through the use of polypropylene strapping. There are 3 modes: manual mode, automatic mode and continuous mode. With an easy operation and high speed, the AAC packaging machine is suitable for AAC production lines.

When in operation, the products waiting for packing are placed in the middle of the AAC packaging machine. The AAC packaging machine will first tighten the strap on the products, then compress the strap (under layer), and finally the heater will be put between the two straps and cut the strap.

Features

The stand is made of aluminum alloy. As a result, the AAC packaging machine is lightweight, durable and exceptionally corrosion resistant. Maintenance requiring lubrication oil is not needed.
The packaging speed is extremely fast, and each AAC packaging machine can work continuously for 16 hours at a time.

Optional Type

1: Horizontal Packaging Machine
Application: The horizontal packaging machine offers single lane or multi lane horizontal packaging for finished products by foot pedal and automatic control. Strapping is bonded together by a hot melt on the bottom of the finished products.

Boundary Dimension: L2780×W2110×H2500mm
Frame Size: W1500mm×H1500mm

2: Vertical Packaging Machine
Application: The vertical packaging machine offers single lane or multi lane vertical packaging for finished products by manual control or photoelectric control.

Boundary Dimension: L3890×W640×H2200mm
Frame Size: W1500mm×H2200mm

Parameters

Power: 380V/50Hz, 3050W/8A
Air Pressure: 0.4-0.6MPa
Packaging Speed: ≤15 sec/lane
Strapping Force: 0-80kg
Tensile Strength : Max 150 kg
Operating Noise: ≤75dB(A)
Ambient Conditions: Relative humidity≤90%, Temperature: 0℃-40℃
Bottom Bonding : Bonding Surface: ≥90%, Bonding Width: ≥20%, Bonding Error: ≤2mm

Requirements About Strapping

Length of Each Roll: About 2000mm
Width of Each Roll: (9mm～15mm)±1mm
Thickness of Each Roll: (0.55mm～1.0mm) ±0.1mm
Inner Diameter of Strap Reel: 200mm～210mm
External Diameter of Strap Reel: 400mm～500mm
