Frame Filter Press

Request a Quote

View All: http://hbminingplant.com/5-2-filter-press.html

Application
Frame filter presses are most often used in industries that require the use of solid/liquid separation equipment. Not only is an outstanding separation process carried out, but the equipment is easily adaptable, and features a number of advantages for the separation of viscous material. Our frame filter press is widely used for sewage treatment solutions in a variety of industries, including chemicals, dyes, petroleum, ceramics, pharmaceuticals, sugar, food, starch, paint and metallurgy.

Technical Parameters

Model	Filter area m²	Number of filter plates	Volume L	Filter plate size mm	Outer frame size L × W × H mm	Weight Kg
500-U/10	10	26	130	500×500	2440×880×1100	850
630-U/10	10	16	100	630×630	2318×1030×1015	1500
630-U/15	15	24	150	630×630	2637×1030×1015	1750
630-U/20	20	32	200	630×630	2957×1030×1015	2000
630-U/30	30	48	300	630×630	3597×1030×1015	2500
800-U/20	20	20	320	800×800	2755×1210×1270	2600
800-U/30	30	30	480	800×800	3355×1210×1270	2900
800-U/40	40	40	640	800×800	3955×1210×1270	3200
800-U/50	50	50	800	800×800	4555×1210×1270	3500
800-U/60	60	60	960	800×800	5155×1210×1270	3800
800-U/70	70	70	1120	800×800	5755×1210×1270	4100
800-U/80	80	80	1280	800×800	6355×1210×1270	4400

Design Details
The filter presses we produce are an intermittent solid-liquid separation equipment. The filter press is composed of the filter plates and filter chambers, which are built with filter frame plates in a board or box arrangement. Under the pressure of the feed pump, materials fed into the filter chamber and pass through the filter medium, thus separating the solid and liquids. We have a filtration area ranging from 10M2 to 500M2, and compression methods that include manual compression, mechanical compression, hydraulic compression and automatic strength packing for customers to choose from.

Main structures

The filter press is composed of a filter plate, a filter frame, filter cloth, and a pressing membrane. Both sides of the filter plate are covered with a filter cloth. When a pressing membrane is required, a filter plate is instead composed of a membrane and a side plate. Both sides of the membrane are coated with a rubber film, above which is the filter cloth, with side plates a common installation for filter plates.

When the filter cake needs to be dried, in addition to pressing with a membrane, air or steam is also compressed and passes through the washing port. The air stream can flush out the water in the filter cake to reduce its moisture content.

Features
• Low energy consumption and long service life
• High concentration and dewatering efficiency, high solid content percentage in filter cakes
• Easy to maintain
• Low noise and less use of chemicals

Customizing Notes
Please provide throughput and material requirements.
