Iron Hoisting Block
Request a Quote
Our iron hoisting block is widely applicable to the erection of overhead line structures, lifting equipment, and other hoisting operations. This product is classified as hook style (G), ring style (H), or clevis style (B). Thus, the style our customer needs must be clearly indicated in the contract when the order is placed.
Technical Parameters
Item Number | Model | Number of Sheave | Rated Load (kN) | Sheave Outer Diameter × Sheave Width (mm) | Rope Diameter (mm) | Weight (kg) | Hoisting Point Type | ||
11181 | QH1-1K | 1 | 10 | Φ100×31 | Φ7.7 | 2.8 | G | H | |
11182 | QH1-2 | 2 | 10 | Φ80×28 | Φ6 | 2.8 | G | H | |
11183 | QH1-3 | 3 | 10 | Φ80×27 | Φ6 | 4.1 | G | H | |
11191 | QH2-1K | 1 | 20 | Φ120×35 | Φ9.3 | 4.2 | G | H | B |
11192 | QH2-2 | 2 | 20 | Φ100×31 | Φ7.7 | 4.2 | G | H | |
11193 | QH2-3 | 3 | 20 | Φ100×31 | Φ7.7 | 6 | G | H | |
11201 | QH3-1K | 1 | 30 | Φ150×39 | Φ11 | 7 | G | H | B |
11202 | QH3-2 | 2 | 30 | Φ120×35 | Φ9.3 | 5.3 | G | H | |
11203 | QH3-3 | 3 | 30 | Φ100×31 | Φ7.7 | 6.5 | G | H | |
11211 | QH5-1K | 1 | 50 | Φ166×40 | Φ13 | 9.6 | G | H | B |
11212 | QH5-2 | 2 | 50 | Φ150×39 | Φ11 | 10.8 | G | H | |
11213 | QH5-3 | 3 | 50 | Φ120×35 | Φ9.3 | 7.7 | G | H | |
11221 | QH8-1K | 1 | 80 | Φ205×50 | Φ17 | 12.5 | G | H | B |
11222 | QH8-2 | 2 | 80 | Φ166×40 | Φ13 | 17 | G | H | |
11223 | QH8-3 | 3 | 80 | Φ150×39 | Φ11 | 17.5 | G | H | |
11231 | QH10-1K | 1 | 100 | Φ246×60 | Φ18.5 | 25 | G | B | |
11232 | QH10-2 | 2 | 100 | Φ166×40 | Φ13 | 18.5 | H | ||
11233 | QH10-3 | 3 | 100 | Φ150×39 | Φ11 | 20 | H | ||
11241 | QH15-1K | 1 | 150 | Φ280×65 | Φ21.5 | 34 | B | ||
11242 | QH15-2 | 2 | 150 | Φ205×50 | Φ17 | 22 | H | ||
11243 | QH15-3 | 3 | 150 | Φ166×40 | Φ13 | 26 | H | ||
11244 | QH15-4 | 4 | 150 | Φ150×39 | Φ11 | 30 | H | ||
11248 | QH20-4 | 4 | 200 | Φ205×50 | Φ17 | 50 | H |
