100L-1000L Lubricant Oil Filling Line

Request a Quote

Website: http://ztpackingmachine.com/6-8-100l-1000l-lubricant-oil-filling-line.html

Suitable bottles

Suitable for filling: Engine oil, lubricating oil, brake oil, grease, etc.
Filling range: 100L-1000L
Filling system: net weight with load cell
Capacity: 30-45 barrels/hour (200L)/ 5 barrels/hour (1000L)

Put the empty drums on the pallets ,conveyor send to filling station ,filling nozzle can be movable front and back , left and right, after finished filling , send to another conveyor and use forklifter to take it away

Specifications

Maximum weight	1200kg
Graduation value	200g
Filling accuracy	±0.2%
Filling speed	200L: 30-45 barrels/hour 1000L: 5 barrels/hour *The actual filling speed depends on the feeding speed of the material and the operating proficiency
Material temperature	≤40℃
Weighing device	1200×1200×90mm
Maximum tray size	1200×1200×150mm
Applicable ambient temperature range	0-40℃
Relative humidity	56-78%, non-condensing
Power supply	380V, 50Hz/1.55kW
Air source pressure	0.6-0.8MPa
Material pressure	≤0.2MPa
Height of feed inlet	1700mm
Diameter of the feed port	Ø 44mm
Outer diameter of filling head	Ø 48mm
Corresponding barrel diameter	≥Ø 58mm
Dimensions	1615×2330×4000mm (L×W×H)
The column of the filling machine needs to be fixed on the ground with expansion screws

Layout drawing
