Hot Water Heater Shut off Valve Automatic Assembly Machine
Request a Quote
Equipped with automated injection system, the automated assembly machine can achieve high-accuracy assembly. The vibratory feeder makes the automatic feeding and places parts to the required position by claw. The electrostatic cleaning system prevents it from dust and static.
Features
- Simple operation by PLC and touch screen
- Automated feeding
- Automated assembly and inspection for separating qualified products and defective goods
- Simultaneous dust removal, quantitative injection, spring feeding, automated packaging and palletizing
Main Units
- Automated Spring Feeder
- Spring Presence/Absence Detection
- Dust Collector
- Rotary Indexing System
- Automated O-ring Assembly
Specifications
- Voltage: 210-240V 5A 50HZ
- Pressure: 0.4-0.6Mpa
- Power: 1-2KW
- Dimension: 3000*2500*1000mm
- Capacity: 2800-3000 pieces/h
