DoubleDisc Refiner
The double disc refiner is an ideal piece of pulping equipment, which is widelyused in waste paper recycling system and paper making industry.
Features
The double disc refiner features compact structure, highwork efficiency, low energy consumption and easy maintenance.
Specificationsof Double Disc Refiner
The double disc refiner features compact structure, highwork efficiency, low energy consumption and easy maintenance.
Specificationsof Double Disc Refiner
| Model | Disc Diameter | Disc Rotating Speed | Stock Pipe Diameter | Inlet Consistency | Capacity | Inlet Pressure | Motor Type | Motor Power |
| ZDP12 | Ø350 | 960RPM | 2× Ø65 | 2.5-5% | 150 | 0.15-0.2MPa | Y | 37KW |
| ZDP | Ø380 | |||||||
| ZDP11 | Ø450 | 300 | 0.15-0.3MPa | Y | 90KW 110KW | |||
| ZDP14 | Ø450 | 200 | 0.15-0.3MPa | Y315S-6 | 110KW | |||
| ZDP13 | Ø500 | Inflowing through two pipes Ø90,Ø125, Inflowing in seriesØ125 | 3-5% | 15-300t/d | 0.15-0.2MPa | Y | 160KW 185KW | |
| ZDP | Ø550 | Y | 220KW | |||||
| ZDP13B | Ø600 | Y | 250KW 280KW |
