Barrel Hoop Forming Machine
Taking the steel belt with specific width as the raw material, the barrel hoop forming machine is specially offered to produce circular product, such as barrel hoop, wheel rim, and so on. Employing hydraulic forming and shearing technology, the barrel hoop making machine is capable of manufacturing the product in different diameters.
Technical Parameters
- Applicable materialStainless steel, carbon steel
- Applicable steel strip width15-52mm
- Applicable steel strip thickness0.8-2.0mm
- Barrel hoop diameter60-1000mm
- Strip feeding speed4m/min
- Roll forming stations5-6 steps
- Roller materialGCr15, quenched, HRC 58-62
- Main drive motor power4kW
- Power supply380V, 3-phase, 50Hz
