Vibrating Feeder

Request a Quote

View All: http://pfcementmachinery.com/7-4-vibrating-feeder.html

The vibrating feeder is able to feed bulk or granular materials to the device which receives the materials uniformly, regularly, and continuously. It can feed materials to the crushing machinery in the sand and gravel production line, and it can coarsely screen those materials.

The vibrating feeder is widely used in the metallurgy, coal mine, building materials, chemical engineering, abrasive, and other industries.

Technical Parameters

Model	Funnel size mm	Max. feed size mm	Capacity t/h	Spindle speed r/min	Motor power KW	Installation slope	Weight (excluding electric motor) kg	Overall dimensions mm
ZSW-300×70	3000×700	≤500	60-120	350-800	7.5	0	3225	3075×1450×1250
ZSW-380×95	3800×950	≤500	100-160	350-800	11	0	4210	3882×1684×1340
ZSW-490×100	4900×1000	≤500	120-200	350-800	15	0	5004	4957×1677×1365
ZSW-360×110	3600×1100	≤500	100-160	350-800	11	0	4321	3700×1805×1195
ZSW-490×110	4900×1100	≤580	200-300	350-800	15	0	6700	4957×1841×1365
ZSW-590×130	5900×1300	≤700	300-400	750	22	5	7900	4957×1841×1365
ZSW-600×110	6000×1100	≤600	400-500	350-800	22	0	8200	6000×1841×1365

Note: The above data are only for reference. The actual data is subject to the signed contract.

Related Names
Vibratory Conveyor | Grizzly Feeder | Shaker Conveyer
