GTY320 Bulldozer

Request a Quote

View All: http://sinomachhiglobal.com/7-5-gty320-bulldozer.html

The appearance of the vehicle is based on optimization design
Higher engine power reserves efficiency ,bigger torque output ,lower fuel consumption ,while better reliability
Hydraulic controlled drive,automatically speed regulation and non-stop gear shifting
3-element,single stage,single phase torque converter for higher efficiency and bigger capacity

Consulting Products Information

The novel hexahedral cad offers excellent visibility, the powerful ventliation and unparalleled dust-free.
The final drive uses triangle Spline and tip lelief, crowned gear drive to enhance the balance and the stability of the load of transmission part
New blade is more durable and capacious
Alarming monitoring system is efficient and reliable
Implement controls are piloted to minimize operating effort

Specifications:

Model	GTY160
Length×Width×Height(mm)	6880×4130×3688
Operating weight (Kg)	37200
Ground pressure（Standard）（MPa）	0.105
Track shoe width （standard）（mm）	560
Traveling speed（km/h）-Forward	0~3.6/6.6/11.5
Traveling speed（km/h）-Reverse	0~4.4/7.8/13.5
Diesel engine	Cummins NT855-C360S10
Rated output(KW)	257

Besides the GTY320 bulldozer, SINOMACH have many other kinds of heavy construction and engineering equipment for sale.
