  • The machine features reasonable layout, excellent performance and advanced technology
  • Higher engine power reserves efficiency ,bigger torque output ,lower fuel consumption ,while better reliability
  • Hydraulic controlled drive,automatically speed regulation and non-stop gear shifting
Consulting Products Information
  • The final drive uses triangle Spline and tip lelief, crowned gear drive to enhance the balance and the stability of the load of transmission part
  • The novel hexahedral cad offers excellent visibility, the powerful ventliation and unparalleled dust-free.
Specifications:
Model GTY160
Length×Width×Height(mm) 5140×3388×3032
Operating weight (Kg) 17000
Ground pressure(Standard)(MPa) 0.067
Track shoe width (standard)(mm) 510
Traveling speed(km/h)-Forward 0~3.3/5.8/9.6
Traveling speed(km/h)-Reverse 0~4.3/7.6/12.5
Diesel engine WEICHAI WD10G178E25
Rated output(KW) 131
