Copper Brazing Ring Making Machine

Features

• PLC-controlled system with HMI interface for fully automated production
• Servo-driven feeding for high speed and high precision
• Flexible adaptation to different ring sizes through interchangeable forming dies
• Equipped with a tapping device for flat brazing rings

Technical Data

• Applicable wire diameter⌀ 0.5-2.0mm
• Applicable ring diameter⌀ 3-20mm
• Suitable ring shapeSingle or multiple circles
• Production speed0-120 rings/min
• Ring diameter accuracy±0.3mm
• Main motor power1.1kW
• Servo motor power3kW
• Heating rod400W x 2pcs
• Main machine dimensionsapprox. 1550 x 950 x 1600mm
• Machine weightapprox. 500kg
