Description of the plate roll bending machine
The plate roll bending machine will adapt to bends in the metal plate material, and is suitable for the production of round, arc, and conical shaped products within certain ranges. This equipment features plate material end component pre-bending, and does so with a high work efficiency. It will also level metal plate material into a flat, smooth surface.

The plate roll bending machine is used in a number of industries, including chemicals, boilers, metal and machine manufacturing.

Parameters
The maximum thickness of the plate roll bending is 8mm

Specification	MAX.thickness(mm)	MAX.width(mm)	Coiling speed(m/min)	Prebending max.thickness(mm)	Min.dia.of full loading(mm)	Dia.of lower roller(mm)	Dia.of lower roller(mm)	Side-low axle diameter(mm)	Motor power(Kw)	Dimension LWH (mm)
W12NC-8 x 2000	8	2000	6.1	6	700	280	260	180	11	5300 x 1400 x 1760
W12NC-8 x 2500	8	2500	6.1	6	750	300	280	230	15	6100 x 2000 x 2070

The maximum thickness of the plate roll bending is 12mm

Specification	MAX.thickness(mm)	MAX.width(mm)	Coiling speed(m/min)	Prebending max.thickness(mm)	Min.dia.of full loading(mm)	Dia.of lower roller(mm)	Dia.of lower roller(mm)	Side-low axle diameter(mm)	Motor power(Kw)	Dimension LWH (mm)
W12NC-12x2000	12	2000	5.45	10	700	300	280	230	15	5600 x 2000 x 2070
W12NC-12x2500	12	2500	5.5	10	750	340	300	260	22	6300 x 2000 x 1200
W12NC-12 x 4000	12	4000	4	10	850	380	340	280	30	7600 x 2000 x 1800

The maximum thickness of the plate roll bending is 16mm

Specification	MAX.thickness(mm)	MAX.width(mm)	Coiling speed(m/min)	Prebending max.thickness(mm)	Min.dia.of full loading(mm)	Dia.of lower roller(mm)	Dia.of lower roller(mm)	Side-low axle diameter(mm)	Motor power(Kw)	Dimension LWH (mm)
W12NC-16x2000	16	2000	5.5	12	750	340	300	260	22	5800 x 2000 x 1800
W12NC-16x2500	16	2500	6.5	12	850	350	320	280	30	6810 x 2000 x 1870

The maximum thickness of the plate roll bending is 20mm

Specification	MAX.thickness(mm)	MAX.width(mm)	Coiling speed(m/min)	Prebending max.thickness(mm)	Min.dia.of full loading(mm)	Dia.of lower roller(mm)	Dia.of lower roller(mm)	Side-low axle diameter(mm)	Motor power(Kw)	Dimension LWH (mm)
W12NC-20x2000	20	2000	6.5	16	850	350	320	280	30	6000 x 2000 x 1850
W12NC-20x2500	20	2500	6.5	16	1000	400	380	320	37	6850 x 2000 x 2070
W12NC-20x3000	20	3000	4.5	16	1100	450	420	350	45	7310 x 2100 x 2200

The maximum thickness of the plate roll bending is 25mm

Specification	MAX.thickness(mm)	MAX.width(mm)	Coiling speed(m/min)	Prebending max.thickness(mm)	Min.dia.of full loading(mm)	Dia.of lower roller(mm)	Dia.of lower roller(mm)	Side-low axle diameter(mm)	Motor power(Kw)	Dimension LWH (mm)
W12NC-25x2000	25	2000	6.5	22	1000	400	380	320	37	6300 x 2300 x 2070
W12NC-25x2500	25	2500	5	22	1100	450	420	350	45	8000 x 2600 x 2100
W12NC-25x3000	25	3000	5	22	1150	540	460	380	55	9000 x 3200 x 2070
W12NC-25x4000	25	4000	4	22	1200	540	500	450	63	10100 x 3500 x 2900

The maximum thickness of the plate roll bending is 30mm

Specification	MAX.thickness(mm)	MAX.width(mm)	Coiling speed(m/min)	Prebending max.thickness(mm)	Min.dia.of full loading(mm)	Dia.of lower roller(mm)	Dia.of lower roller(mm)	Side-low axle diameter(mm)	Motor power(Kw)	Dimension LWH (mm)
W12NC-30x2000	30	2000	5	25	1100	450	420	350	45	7500 x 2600 x 2500
W12NC-30x2500	30	2500	4.5	25	1150	480	460	380	55	8400 x 2590 x 2600
W12NC-30x3000	30	3000	4	25	1300	560	520	420	60	9200 x 3500 x 2900
W12NC-30x4000	30	4000	4	25	1500	650	600	480	60	10200 x 3500 x 2900

The maximum thickness of the plate roll bending is 40mm

Specification	MAX.thickness(mm)	MAX.width(mm)	Coiling speed(m/min)	Prebending max.thickness(mm)	Min.dia.of full loading(mm)	Dia.of lower roller(mm)	Dia.of lower roller(mm)	Side-low axle diameter(mm)	Motor power(Kw)	Dimension LWH (mm)
W12NC-40x2000	40	2000	4.5	36	1200	520	500	400	45	8200 x 3000 x 2900
W12NC-40x2500	40	2500	4	36	1300	560	520	420	60	8700 x 3500 x 2900
W12NC-40x3000	40	3000	4	36	1500	650	580	480	75	9200 x 3600 x 3000
W12NC-40x4000	40	4000	3.5	36	1800	710	650	500	86	12500 x 4000 x 3500

The maximum thickness of the plate roll bending is 50mm

Specification	MAX.thickness(mm)	MAX.width(mm)	Coiling speed(m/min)	Prebending max.thickness(mm)	Min.dia.of full loading(mm)	Dia.of lower roller(mm)	Dia.of lower roller(mm)	Side-low axle diameter(mm)	Motor power(Kw)	Dimension LWH (mm)
W12NC-50x2000	50	2000	4	45	1500	650	580	480	60	8500 x 3500 x 3000
W12NC-50x2500	50	2500	4.5	45	1550	680	620	500	75	9000 x 4000 x 3300
W12NC-50x3000	50	3000	4	45	1800	720	650	520	90	9800 x 4300 x 3500

The maximum thickness of the plate roll bending is 60mm

Specification	MAX.thickness(mm)	MAX.width(mm)	Coiling speed(m/min)	Prebending max.thickness(mm)	Min.dia.of full loading(mm)	Dia.of lower roller(mm)	Dia.of lower roller(mm)	Side-low axle diameter(mm)	Motor power(Kw)	Dimension LWH (mm)
W12NC-60x2500	60	2500	4	50	1800	700	650	500	90	9500 x 4500 x 3700
W12NC-60x3000	60	3000	4.5	50	1800	750	710	560	121	10000 x 4500 x 3800

Jiashida is a sheet metal fabrication equipment manufacturer and supplier, offering all kinds of sheet metal metalwork machinery like hydraulic shear, press brake, punch press, plate roll bender and sheet metal shears, metal benders. We have well trained and experienced team and fully equipped machining equipment to guarantee that we offer good quality metalworking machines.
