Crawler Dozer, FK14-086T
Request a Quote
Basic Information
-
- Total weight
- 8600kg
-
- Max. towing force
- 82kN
-
- Track width
- 400mm
-
- Ground pressure
- 51kPa
-
- Rated power
- 66.2kW
-
- Cutting angle (adjustable)
- 55°
Technical Specifications
- Total weight: 8600kg
- Max. towing force: 82kN
- Engine model: Yuchai
- Engine rated power/speed: 66.2/2200kW/rpm
- Fuel consumption of engine: ≤225g/kW.h
- Max. torque of engine: 345N.m
- Forward travel speed (1-4 gear): 2.4-10.4km/h
- Reverse travel speed (1-2 gear): 4.9-8.9km/h
- Track width: 400mm
- Ground pressure: 51kPa
- Overall dimensions (L×W×H): 4200×2480×2740mm
- Bulldozer shovel (W×H): 2480×922mm
- Max. lifting height of blade: 736.5mm
- Max. digging depth of blade: 370mm
- Cutting angle (adjustable): 55°
- Towing equipment/scarifier (optional): fixed/three teeth
- Booster
- Car air conditioner
- Protective device
- GPS positioning
- On-board repair tools
- CD player
- Fire extinguisher
FUKE provides cost-effective flexible customization service of bulldozers. Whether you are OEM, wholesaler, or project construction side, or individuals, welcome to discuss with our designers!
