Vaccine Carrier Box
Request a Quote
Multi-use passive cooled boxes of 2-8°C with up to 48-72 hours retention with optional remote monitoring capability.
Features
- Combination of high performance VIP and EPP
- Operating environment: -30℃~60℃
- Temperature range: optional (10~20℃, 2~8℃, -1~3℃, -15~-25℃)
- Duration time: more than 72h
- Customized mold acceptable
Applications
Portable heat preservation demand for storage and deliveries of pharmaceuticals, fresh and food, etc.
Specifications
| Box type | Internal size | External size | Internal volume | Box weight | Box thickness | Insulation time（2~8℃） | PCM weight |
| STEPP-V12 | 300*200*190 | 400*300*300 | 12L | 3.3kg | 50mm | 48h | 4.7kg |
| STEPP-V28 | 370*270*290 | 490*380*400 | 29L | 7.6kg | 55mm | 60h | 7.7kg |
| STEPP-V33 | 540*390*330 | 660*510*478 | 71.6L | 12.2kg | 60mm | 72h | 15kg |
| STEPP-V54a | 630*550*450 | 760*680*580 | 156L | 20kg | 60mm | 72h | 23.2kg |
