MPSB-W Pilot Control Valve Block
Request a Quote
Hydraulic pilot manifold valve for compact excavators
- Space-efficient, compact structure designed for easy installation on wheel excavators
- Fully tested and validated to meet high performance and safety standards
- Provides precise pilot pressure control and pressure-holding capability, with an optimized design that reduces operational noise and improves overall control; fully developed in-house for consistent quality
Applications
Designed for mini excavators, this pilot control valve block delivers stable, clean, and controllable low-pressure hydraulic oil to the pilot control system. It ensures responsive handling, safe operation, and improved energy efficiency, enabling operators to maintain precise control in confined or delicate work environments.
Specifications
| Rated Pressure | 40bar |
| Rated Flow | 20L/min |
| Solenoid Valve Voltage | DC14V±15% |
| Proportional Valve Voltage | DC12V±15% |
| Fluid Temperature Range | -20℃～80℃ |
| Ambient Temperature Range | -20℃～80℃ |
| Oil Viscosity Range | ISO 20～400mm²/s |
