Pair-twisting
Request a Quote
Suitable for pair-twist cat5e, cat6, cat7 insulation core wire
Parameters- Pay-off reel diameter: 500mm
- Take-up reel diameter: 500mm
- Single wire diameter: max 1.5mm
- Rotation speed: max 2000rpm (6000TPM)
- Line speed: max 120m/min
- Back-twist ratio: 0 – 100%
- Pitch range: 10 – 60mm
- Pitch tolerance: ±.2%
- Main power: 5.5KW
