H Series Symons Cone Crusher
The multi-cylinder symons cone crusher is developed based on years of mining machinery research experience, incorporating advanced crushing technologies from both domestic and international sources. It is a fully symons cone crusher of excellent quality, utilizing cutting-edge technologies like inter-particle crushing principle, high-precision manufacturing processes, and advanced intelligent control systems.
- Metal Ores
- Non-Metal Ores
- Optimized Crushing Chamber Design
Improves product shape, increases the proportion of cubic particles, reduces the amount of flaky particles, and enhances the crushing quality. A longer crushing chamber and greater retention force improve throughput.
- Efficient Conversion of Horsepower into Crushing Force
The optimized design allows more horsepower to be converted into crushing force, reducing friction and heat, thus increasing production and extending bearing life.
- Enhanced Load Capacity
The load capacity of key components is increased, making it suitable for crushing high-hardness metal ores and improving the durability of the equipment.
- Heavy-Duty Cast Steel Frame
The high-strength cast steel structure withstands harsh working conditions and prolongs service life.
- Hydraulic Control System
Simple discharge port adjustment and reliable overload protection system enhance equipment safety.
- Automation Control System
Simplifies operation, improves stability, and reduces manual intervention.
- Replaceable Liners
Easily replaceable liners allow for smooth conversion between coarse and fine crushing modes, meeting a variety of operational needs.
| Model | ||
| Length L1 (mm) | 5080 | 5020 |
| Width W1 (mm) | 4080 | 5055 |
| Height H1 (mm) | 3300 | 3310 |
| Height H2 (mm) | 4320 | 4330 |
| Model | Cavity | Max. feeding size (mm) | Feed opening (mm) | Discharging size (mm) | Capacity (t/h) | Power (kW) | ||
| Closed side | Open side | |||||||
| Short head type | Fine | 180 | 51 | 105 | 6-16 | 315-475 | 450 | |
| Medium | 180 | 95 | 133 | 10-19 | 410-590 | 450 | ||
| Coarse | 180 | 127 | 178 | 13-25 | 525-695 | 450 | ||
| Extra coarse | 180 | 152 | 203 | 16-25 | 588-756 | 450 | ||
| Standard type | Fine | 400 | 253 | 278 | 19-38 | 565-840 | 450 | |
| Medium | 400 | 303 | 334 | 25-51 | 705-1160 | 450 | ||
| Coarse | 400 | 334 | 369 | 31-89 | 910-1450 | 450 | ||
| Extra coarse | 400 | 425 | 460 | 60-130 | 1000-1550 | 450 | ||
| Short head type | Fine | 200 | 60 | 120 | 10-16 | 560-670 | 710 | |
| Medium | 200 | 100 | 150 | 13-19 | 670-810 | 710 | ||
| Coarse | 200 | 130 | 190 | 16-22 | 770-1000 | 710 | ||
| Extra coarse | 200 | 160 | 220 | 19-25 | 920-1190 | 710 | ||
| Standard type | Fine | 450 | 245 | 330 | 45-250 | 700-1200 | 710 | |
| Medium | 450 | 280 | 375 | 60-250 | 1050-1900 | 710 | ||
| Coarse | 450 | 380 | 465 | 70-250 | 1300-2500 | 710 | ||
| Extra coarse | 450 | 460 | 495 | 80-250 | 1500-2600 | 710 | ||
