DH/DS Series Symons Cone Crusher
Request a Quote
The single-cylinder symons cone crusher features overload automatic uncrushable material release, automatic chamber clearing, and an intelligent control system that enables automatic adjustment of the discharge opening, with real-time display of working status and fault warnings. It is suitable for crushing raw materials in industries such as metallurgy, construction, road building, chemicals, and silicates, and can crush various ores and rocks of medium and above medium hardness.
Applicable Materials
- Metal Ores
- Non-Metal Ores
Features
- Optimized overall machine design with a large-diameter, high-strength main shaft and a heavy-duty main frame, ensuring excellent rigidity and long service life.
- Heavy-duty rolling bearings replace traditional bronze bushings, reducing assembly clearance and increasing main shaft swing speed, resulting in higher output and improved particle shape.
- Hydraulic control system enables easy discharge opening adjustment and provides more reliable overload protection.
- Stroke can be adjusted according to material characteristics, allowing the crusher to adapt to different crushing requirements.
- Advanced automatic control system improves product quality while maintaining maximum crushing efficiency within safe operating limits.
- Application of the “laminated crushing” principle, combined with optional speed settings, steep-angle chambers, and double-curved crushing chamber designs, ensures uniform and consistent product particle shape.
- The upper frame is divided into a main arm frame and a mantle support seat, allowing independent maintenance in case of damage and reducing maintenance costs.
- Spiral bevel gear transmission increases load-bearing capacity and ensures smoother, more stable operation.
Dimensions
| Model | Length L1 (mm) | Width W1 (mm) | Height H1 (mm) |
| | 1500 | 1300 | 2460 |
| | 1935 | 1860 | 2630 |
| | 2484 | 2150 | 3230 |
| | 2700 | 2450 | 3560 |
| | 3394 | 2870 | 4625 |
| | 3621 | 3100 | 5280 |
| | 1500 | 1300 | 2820 |
| | 1935 | 1860 | 3130 |
| | 2484 | 2150 | 3750 |
| | 3394 | 2450 | 4750 |
| | 3520 | 2870 | 5900 |
Technical Parameters
| Model | Max. feeding size (mm) | Discharging size (mm) | Capacity (t/h) | Power (kW) |
| | 135 | 4-32 | 27-128 | 90 |
| | 185 | 6-38 | 48-208 | 132 |
| | 215 | 8-44 | 90-395 | 220 |
| | 275 | 13-51 | 192-662 | 315 |
| | 300 | 10-70 | 280-1512 | 560 |
| | 370 | 16-70 | 368-2600 | 750 |
| | 240 | 19-38 | 70-168 | 90 |
| | 360 | 19-54 | 91-344 | 132 |
| | 450 | 25-54 | 195-601 | 250 |
| | 560 | 38-83 | 318-1050 | 355 |
| | 600 | 60-120 | 1200-2000 | 630 |
Projects
Aggregate Plant Project of Wuzhou City Construction Investment Group in Guangxi (15 million tons per year)Aggregate Plant Project of Fenglin Mining Company in GuangxiEPCO Green Building Materials Processing Project of Changtou Jinrunyuan in HubeiAggregate Plant Project of China Gezhouba Group in Ding'an, Hainan
For a mid-size granite quarry seeking a turnkey solution with an emphasis on particle shape, what configuration is suitable?
A configuration consisting of a jaw crusher for primary crushing, a multi-cylinder symons cone crusher for medium and fine crushing in a closed circuit, combined with a VSI shaping stage, can significantly improve particle shape.
When processing materials such as iron ore and basalt, can a single-cylinder symons cone crusher deliver efficient fine crushing and precise discharge control?
With a high-energy hydraulic drive system and intelligent automatic control technology, the single-cylinder symons cone crusher provides strong fine crushing capability and precise discharge adjustment. It maintains stable crushing force and uniform particle size when handling high-hardness ores, producing finished products with excellent particle shape and controllable gradation.
