LMC Series Symons Cone Crusher
Request a Quote
This comprehensive cone crusher combines both spring and hydraulic cylinder systems. It is suitable for crushing materials of medium hardness and above.
It is mainly used in industries such as mining, chemical processing, road and bridge construction, and building materials. The crusher is suitable for medium and fine crushing of various ores and rocks with compressive strength below 300MPa, including iron ore, non-ferrous metal ores, basalt, granite, limestone, and river pebbles.
Applicable Materials
- Metal Ores
- Non-Metal Ores
Dimensions
| Model | Length L1 (mm) | Width W1 (mm) | Height H1 (mm) | Height H2 (mm) |
| 2670 | 2000 | 1750 | 2250 | |
| 3000 | 2650 | 2330 | 3030 | |
| 3255 | 2650 | 2400 | 3240 | |
| 3500 | 2860 | 2765 | 2620 |
Technical Parameters
| Model | Max. feeding size (mm) | Discharging size (mm) | Capacity (t/h) | Power (kW) |
| | 180 | 10-38 | 60-260 | 132 |
| | 215 | 10-51 | 122-440 | 220 |
| | 235 | 10-64 | 148-580 | 240 |
| | 267 | 10-64 | 180-725 | 320 |
Projects
Aggregate Plant Project in the PhilippinesAggregate Plant Project in KazakhstanAggregate Plant Project in Wenchuan, Sichuan (5 million tons per year)Aggregate Production Line Project in Chonburi, ThailandAggregate Plant Project in IndonesiaAggregate Production Line Project in Binh Phuoc, VietnamAggregate Plant Project in Cambodia
For river pebble sand making lines, what crusher configuration is often chosen to control grain shape?
River pebble sand making lines commonly use a cone crusher for pre-crushing followed by a VSI crusher for sand making and shaping, which improves particle shape and controls flaky particles.
What does a “hard rock crushing plant” typically require compared with soft rock lines?
Hard rock crushing plants require higher crushing force and enhanced wear-resistant configurations, and the process typically adopts a combination of jaw crushers and cone crushers.
