17kW-65kW Diesel Generator Set
Request a Quote
Cummins Engine Series
Powered by Cummins diesel engine
Cummins engine series diesel generator sets offer dependable and efficient backup power solutions for residential, commercial, and industrial environments. These generators are renowned for their robustness, requiring minimal maintenance. With a wide range of sizes and configurations, our Cummins engine series diesel generator sets can fulfill the unique requirements of any user. Whether you need a compact portable generator or a substantial industrial unit, there is a Cummins series available to suit your budget and application. Below, you will find the detailed specifications for our 17-65KW Cummins engine series diesel generator sets.
17kW 20kVA
Diesel Generator Set with Cummins Engine, DB-17GF
- Prime power: 17kW/20kVA
- Standby power: 19kW/24kVA
- Rated current: 31A
- Rated voltage: 400V/230V Customized
- Frequency: 50Hz
- Engine: Cummins 4B3.9-G11
- Alternator: Stamford/Leroy Somer/Engga (optional)
22kW 27kVA
Diesel Generator Set with Cummins Engine, DB-22GF
- Prime power: 22kW/27kVA
- Standby power: 24kW/30kVA
- Rated current: 40A
- Rated voltage: 400V/230V Customized
- Frequency: 50Hz
- Engine: Cummins 4B3.9-G1
- Alternator: Stamford/Leroy Somer/Engga (optional)
25kW 31kVA
Diesel Generator Set with Cummins Engine, DB-25GF
- Prime power: 25kW/31kVA
- Standby power: 27.5kW/34kVA
- Rated current: 45A
- Rated voltage: 400V/230V Customized
- Frequency: 50Hz
- Engine: Cummins 4B3.9-G12
- Alternator: Stamford/Leroy Somer/Engga (optional)
32kW 40kVA
Diesel Generator Set with Cummins Engine, DB-32GF
- Prime power: 32kW/40kVA
- Standby power: 35kW/44kVA
- Rated current: 58A
- Rated voltage: 400V/230V Customized
- Frequency: 50Hz
- Engine: Cummins 4BT3.9-G1
- Alternator: Stamford/Leroy Somer/Engga (optional)
45kW 56kVA
Diesel Generator Set with Cummins Engine, DB-45GF
- Prime power: 45kW/56kVA
- Standby power: 50kW/62kVA
- Rated current: 81A
- Rated voltage: 400V/230V Customized
- Frequency: 50Hz
- Engine: Cummins 4BTA3.9-G2
- Alternator: Stamford/Leroy Somer/Engga (optional)
52kW 65KVA
Diesel Generator Set with Cummins Engine, DB-52GF
- Prime power: 52kW/65kVA
- Standby power: 56kW/70kVA
- Rated current: 94A
- Rated voltage: 400V/230V Customized
- Frequency: 50Hz
- Engine: Cummins 4BTA3.9-G2
- Alternator: Stamford/Leroy Somer/Engga (optional)
64kW 80kVA
Diesel Generator Set with Cummins Engine, DB-64GF
- Prime power: 64kW/80kVA
- Standby power: 72kW/90kVA
- Rated current: 115.2A
- Rated voltage: 400V/230V Customized
- Frequency: 50Hz
- Engine: Cummins 4BTA3.9-G11
- Alternator: Stamford/Leroy Somer/Engga (optional)
- Engine
- Speed: 1500rpm
- Cylinders No. & Type: 4 cylinders, Inline, 4 stroke, diesel engine, water-cooled
- 24V stater and charge alternator
- Cooling radiator and fan
- Maintenance free battery including ract and cable
- Flexible fuel connection hoses and manual oil sump drain valve
- Exhaust silencer
- Machinery or electronic governing
- Fuel injection pump
- Electric motor starting system
- Forged steel crankshaft, cast iron cylinder and replaceable wet type cylinder liner
- Low discharge, and low fuel consumption
- Installed conveniently and maintain easily
- Alternator
- Optional brand: Stamford/Leroy Somer/Marathon/ENGGA
- Exciter: Brushless, Self-exciter
- Motor: single bearing
- Rated power factor: 0.8
- Protection class: IP23
- Insulation class: H
- Self-exciting and Self-regulation
- Control System
- Controller brand: Deepsea , Smartgen
- Automatic controller, integrating digital, intelligent and network techniques, is used for automatic control and monitoring system of genset. It can carry out functions of automatic start/stop, data measurement, alarm protection and three remote (remote control, remote measure and remote communication).
- Optional language interface: English, Spanish, Russian, Portuguese, Turkish, Polish and French with easy and reliable operation.
- Control and Protection of the Generator Set Includes: High water temperature, low oil pressure, over and under speed, over current, under/over generator voltage, start and stop failure, low and high battery voltage, charge fail, emergency stop.
Contact Do you have any questions about this generator set?
Whether you are looking for a specific brand of diesel generator or need some help to make up your mind as to the best solution for your power generation needs, our experts are on hand to help ensure the decision making process is easy for you.
