FRP Counterflow Cooling Tower (Standard Type)
Request a Quote
This standard FRP cooling tower is counterflow designed, and features a round shape. It is an ideal solution for choosing heat rejection devices that depend on specific circulating water, especially if the flow rate requirements are between 10m3/h and 1000m3/h. For more details, please see the following direct heat rejection equipment. If they do not meet your needs, we also offer customization services according to your specific requirements.
Design condition
- Inlet water temperature: T1=37℃
- Outlet water temperature: T2=32℃
- Wet bulb temperature: TWB=27℃
- Dry bulb temperature: T=31.8℃
- Atmospheric pressure: P=9.94×104 Pa
Model | Flow Rate (m3/h) | Overall Dimension | Fan Assembly | Piping Size | Noise (dB) | |||||||
WB28℃ | WB27℃ | Height H | Outer Diameter D | Motor (hp) | Fan | Warm Water Inlet | Cold Water Outlet | Drain Pipe DR | Overflow Pipe OF | Feed Pipe FV | ||
TWB28℃ | TWB27℃ | |||||||||||
LCT-10 | 7.2 | 8.5 | 1740 | 1060 | 1/4 | 670 | 40 | 40 | 25 | 25 | 15 | 50 |
LCT-15 | 10.8 | 12 | 1960 | 1060 | 1/4 | 670 | 40 | 40 | 25 | 25 | 15 | 52 |
LCT-20 | 14.4 | 17 | 2000 | 1200 | 1/4 | 670 | 50 | 50 | 25 | 25 | 15 | 53 |
LCT-25 | 18.5 | 20 | 2290 | 1430 | 1/2 | 770 | 80 | 80 | 25 | 25 | 15 | 53 |
LCT-30 | 21.6 | 24 | 2290 | 1430 | 3/4 | 770 | 80 | 80 | 25 | 25 | 15 | 55 |
LCT-40 | 28.8 | 32 | 2360 | 1620 | 1 | 770 | 80 | 80 | 25 | 25 | 15 | 56 |
LCT-50 | 36 | 40 | 2595 | 1810 | 2 | 970 | 80 | 80 | 25 | 25 | 15 | 57 |
LCT-60 | 43.2 | 48 | 2595 | 2000 | 2 | 970 | 80 | 80 | 25 | 25 | 15 | 58 |
LCT-80 | 57.6 | 64 | 2690 | 2180 | 2 | 1170 | 100 | 100 | 25 | 25 | 25 | 59 |
LCT-100 | 72 | 80 | 2790 | 2180 | 2 | 1170 | 100 | 100 | 40 | 25 | 25 | 60 |
LCT-125 | 90 | 100 | 2875 | 2750 | 3 | 1470 | 100 | 100 | 40 | 25 | 25 | 61 |
LCT-150 | 108 | 120 | 2950 | 3070 | 3 | 1470 | 125 | 125 | 50 | 25 | 25 | 61 |
LCT-175 | 126 | 140 | 3200 | 3300 | 5 | 1750 | 125 | 125 | 50 | 50 | 25 | 62 |
LCT-200 | 144 | 160 | 3300 | 3300 | 5 | 1750 | 125 | 125 | 50 | 50 | 25 | 62 |
LCT-250 | 180 | 200 | 3600 | 3770 | 5 | 1750 | 150 | 150 | 50 | 50 | 40 | 63 |
LCT-300 | 216 | 240 | 3960 | 3770 | 7.5 | 2400 | 200 | 200 | 50 | 50 | 40 | 63 |
LCT-350 | 252 | 280 | 4150 | 4790 | 10 | 2400 | 200 | 200 | 50 | 50 | 40 | 63.5 |
LCT-400 | 288 | 320 | 4150 | 4790 | 10 | 2400 | 200 | 200 | 50 | 50 | 40 | 63.5 |
LCT-500 | 360 | 400 | 5200 | 5480 | 15 | 3000 | 250 | 250 | 80 | 80 | 40 | 65 |
LCT-600 | 432 | 480 | 5200 | 6100 | 15 | 3400 | 250 | 250 | 80 | 80 | 40 | 66 |
LCT-700 | 504 | 560 | 5770 | 6600 | 20 | 3400 | 250 | 250 | 80 | 80 | 40 | 68 |
LCT-800 | 576 | 640 | 5820 | 6600 | 20 | 3400 | 250 | 250 | 80 | 80 | 40 | 69 |
LCT-1000 | 720 | 800 | 5920 | 7600 | 30 | 3600 | 300 | 300 | 80 | 80 | 40 | 69 |
