Manual Horizontal Band Saws Manufacturer

Manual Horizontal Band Saws

Request a Quote

View All: http://bandsaw-factory.com/1-1-3-manual-band-saws.html

If you need to cut small-sized parts, for example cables, woods and tubes, manual horizontal band saw is well recommended. Manual band saw is easy to transport because of its small size and light weight, the lightest weighs only 19kg. Besides, this type of band saw costs much less than semi-automatic or automatic saws.

The following 4 types of manual horizontal band saws can all fulfill your basic needs about metal cutting. The cutting is suitable for materials with the maximum height of 178mm and the maximum width of 305mm, the miter cutting angle is from 0°-45°. Based on the hardness of the material, you can choose from 2 different blade speeds.

BS-85 Mitering Horizontal Manual Band Saw

Technical parameters		Bs-85
Capacity	Round@90°	85mm(3.3″)
	Rectangle@90°	85x105mm(3.3″×4.1″)
	Round@45°	70mm(2.7″)
	Rectangle@45°	65×75mm(2.5″×2.9″)
Blade speed	@60hz	40-~88mpm
	@50Hz	40~88MPM
Blade size		13×0.65×1325mm
Blade motor		1000w
Drive		Gear
Package size		72×37×46cm
Weight		19kg

BS-100 Mitering Horizontal Manual Band Saw

Technical parameters		Bs-100
Capacity	Round@90°	100mm(4″)
	Rectangle@90°	100×150mm(4″×6″)
	Round@45°	60mm(2.4″)
	Rectangle@45°	60×100mm(2.4″×4″)
Blade speed	@60hz	54mpm
	@50Hz	45MPM
Blade size		13×0.65×1470mm
Blade motor		375w 1/2hp(3ph),550w 3/4hp（1ph)
Drive		Gear
Package size		72×37×46cm
Weight		26kg

BS-115 Metal Cutting Manual Band Saw

Technical parameters		Bs-115
Cutting capacity	Round@90°	115mm(4.5″)
	Rectangle@90°	100×150mm(4″×6″)
	Round@45°	60mm(2.4″)
	Rectangle@45°	60×100mm(2.4″×4″)
Blade speed	@60hz	24,35,61mpm
	@50Hz	20,29,50MPM
Blade size		13×0.6×1638mm
Blade motor		375w 1/2hp(3ph),550w 3/4hp（1ph)
Drive		V-belt
Package size		97×46×46cm
Weight		68kg

BS-712N Metal Cutting Manual Band Saw

Technical parameters		Bs-712n
Cutting capacity	Round@90°	178mm(7″)
	Rectangle@90°	178×305mm(7″×12″)
	Round@45°	127mm(5″)
	Rectangle@45°	120×125mm(4.75″×4.88″)
Blade speed	@60hz	27,41,59,78mpm
	@50Hz	22,34,49,64MPM
Blade size		20x0.9x2362mm
Blade motor		750w 1hp(3ph),1.1kw 1.5hp（1ph)
Dive		Belt
Package size		125×51×115cm
Weight		150kg
