40-80kW Induction Heating Power Supply (Wall Mounted)
Request a Quote
Output power (optional):40kW, 60kW, 80kW
Input voltage: 380V
Frequency: 5-30kHz
Cooling method: Air cooled/Water cooled
Mounting method: Wall mounted
Send
Model | Unit | BYD-PB40Q1S04G21 | BYD-PB60Q1S04G21 | BYD-PB80Q1S04G21 |
BYD-PB40Q1S04G21-W02/W04 | BYD-PB60Q1S04G21-W02/W04 | BYD-PB80Q1S04G21-W02/W04 | ||
BYD-PB040Q1F10G19 | BYD-PB060Q1F10G19 | BYD-PB080Q1F11G20 | ||
BYD-PB040Q1F10G19-W02/W04 | BYD-PB060Q1F10G19-W02/W04 | BYD-PB080Q1F11G20-W02/W04 | ||
Output power | kW | 40 | 60 | 80 |
Current | A | 60 | 90 | 120 |
Input voltage/Frequency | V/Hz | 380/50-60 | 380/50-60 | 380/50-60 |
Supply voltage | V | 340-420 | 330-420 | 330-420 |
Cross section area of power cable | mm² | ≥16 | ≥25 | ≥35 |
Heating efficiency | % | ≥98 | ≥98 | ≥98 |
Operating frequency range | KHz | 5-30 | 5-30 | 5-30 |
Thickness of insulation cotton | mm | 20-25 | 20-25 | 20-25 |
Inductance | uH | 200±5 | 150±5 | 130±5 |
Cross section area of heating wire | mm² | ≥25 | ≥25 | ≥35 |
Dimensions (air cooled) | mm | 600*310*265 | 600*310*265 | 615*325*300 |
Dimensions (water cooled) | mm | 655*240*310 | 655*240*310 | 655*240*310 |
Power adjustment range | % | 10-100 | 10-100 | 10-100 |
Cooling method | / | Air cooled/Water cooled | ||
Weight | Kg | 25 | 25 | 30 |
40-60KW 80KW Installation
- Cut the insulation cotton according to the workpiece diameter;
- Wrap the insulation cotton around the workpiece and tighten it using high temperature wire, the thickness of insulation cotton should be within a range of 20-25mm;
- Wind the induction heating coil around the insulation cotton wrapped workpiece;
- When 2 sets of coils are required to be wound on the same workpiece, the optimal spacing in between is more than150mm to prevent interference;
- Two ends of coil are crimped with wire terminals and then connected to the outputs L1 and L2 of induction heating power supply.
