YIHUA-1501DA DC Power Supply
Request a Quote
- Output voltage: 0-15V adjustable, current: 0-1A / 0-100mA adjustable
- With reliable quality, YIHUA-1501DA DC power supply works stably and can be used for a long time.
- In addition to the short circuit protection function and automatic recovery function, it has a voltage test function. The test voltage is 0-49.9V.
- This DC power supply has RF signal function.
- It offers two kinds of output current, such as 0-1A and 0-100mA.
General Information | ||
Rated Voltage | AC220V 50Hz | |
Whole Machine Power | 20W | |
Working Condition | 0 ~ 40 ℃ relative humidity < 80 % | |
Storage Temperature | -20 ~80 ℃ relative humidity <80 % | |
Dimensions | 205*140*200mm | |
Weight | 1.67KG | |
Performance | ||
Output Voltage | 0 ~ 15V | |
Output Current | 0-1A/0-100mA | |
Source Effect | 1.5mV | |
Loading Effect | ≤0.13% | |
Ripple and Noise | ≤4mV | |
Power Stability | ≤0.5% | |
Measurement Accuracy | 0.1V | |
Protected Mode | Short circuit over-current protection, automatic recovery function | |
Mobile Phone Signal Indicator | RF | |
Phones Emission Interference | Anti-interference |
Application
This DC power supply is chiefly used to provide 0-15V DC power output, or applied to test 0~49.9V DC voltage. Since it also can offer 0-100mA output current, the test will be more accurate. The product is commonly found in the mobile phone maintenance and other related industries.
Related Names
China DC Power Source | Stabilized Power Supply | Cell Phone Detection Power Supply
