Fixed Displacement Axial Piston Pump for Open Circuit Manufacturer

Fixed Displacement Axial Piston Pump for Open Circuit

Request a Quote

View All: http://hydraulicsystem-en.com/1-1-6-fixed-displacement-pump.html

The HL-A4FO fixed displacement pump is designed to provide stable, high-pressure hydraulic power for your industrial and construction applications. Our fixed displacement pump combines efficiency, durability, and precise control, ensuring seamless integration into your system and consistent performance under demanding conditions.

Displacement 40-500 cm³/rev
Nominal pressure 350 bar
Max. allowable pressure 400 bar

Technical Data

Size			40	71	125	250	500
Displacement	V_gmax	cm³/rev	40	71	125	250	500
Max. rotation speed	n_max	rpm	2750	2200	1800	1500	1320
Max. flow	at n=n_max	L/min	110	156	225	375	660
Max. power	(Δp=350 bar)	kW	64	91	131	219	385
Max. torque	(Δp=350 bar)	Nm	223	395	696	1391	2782
Weight	approx.	kg	17	35	62	122	233

Features

Consistent and Powerful Performance The swashplate mechanism ensures steady hydraulic output, delivering reliable results.
Precision Flow Control Flow adjusts proportionally to speed and displacement, maintaining accuracy across applications.
Optimized Suction Capability Engineered for continuous and stable fluid intake, even in challenging conditions.
Long-Lasting Durability High-precision bearings extend service life, reducing wear and maintenance requirements.
Compact and Space-Saving Design Designed to fit efficiently within hydraulic systems without compromising performance.
Low-Noise Operation Minimizes vibration and sound levels, improving workplace efficiency.
Enhanced Wear Resistance Hydrostatic balanced shoes increase durability and reduce component wear over time.

Applications

High-Speed Forging Press

This axial piston pump delivers the efficiency and reliability your hydraulic system demands. Contact us today to explore how it can improve your operations.
