HDPE Pipe Coupling
Product Introduction
The design for HDPE couplings provide added strength for high pressure applications.
The high pressure coupling provides versatility for a wide range of applications due to its high pressure resistance and flexibility. The HDPE coupling is suitable for mechanical and plumbing, water treatment, mining and oil fields, and a variety of other process pipe systems.
Features
Ductile iron construction
Lead free orange paint (available galvanized)
Approvals: UL listed, FM approved, ASTM A536
Dimension DrawingTechnical Data
Nominal Size mm/in | Pipe O.D mm/in | Dimensions | Bolt/Nut | ||
ΦD | L | H | Size (mm) | ||
mm | mm | mm | |||
50 | 63 | 85 | 128 | 105 | 3/8×2-1/8 (M10×55) |
2 | 2.5 | ||||
80 | 90 | 110 | 169 | 105 | 1/2×3 (M12×75) |
3 | 3.5 | ||||
100 | 110 | 138 | 181 | 113 | 1/2×3 (M12×75) |
4 | 4.3 | ||||
150 | 160 | 190 | 261 | 147 | 5/8×3-1/2 (M16×90) |
6 | 6.3 | ||||
200 | 200 | 233 | 319 | 154 | 5/8×3-1/2 (M16×90) |
8 | 7.9 | ||||
250 | 250 | 287 | 351 | 136 | 5/8×4-3/4 (M16×120) |
10 | 9.8 | ||||
300 | 315 | 351 | 442 | 136 | 3/4×4-3/4 (M20×120) |
12 | 12.4 |
HDPE: high-density polyethylene
Other Image Gallery of HDPE Pipe Grooved CouplingLEDE company design and manufacture grooved piping system jointing fittings, is a leading China HDPE piping system coupling manufacturer and supplier, provide pipe jointing and flow control products of fire protection system and water work system. There are different sizes of HDPE pipe couplings for grooved piping system, made in accordance with UL, CE, ISO certificates, etc. Engineered with complete automation equipment and manufacturing expertise, LEDE company provides quality ductile iron pipe coupling as well as custom firefighting and water supply solutions based on the client needs.
