Application
Glossy PE coating aluminum composite panel is mainly applied in some places where there is demanding requirement towards color and brightness. When used in outdoor places where sun shines on them, our PE coated ACPs will enjoy an even more outstanding and colorful effect.

Features
Our glossy PE coated aluminum composite panel gets rid of the disadvantages of traditional ACP and possesses many extra outstanding properties, like, gorgeousness, decorativeness, weather resistance, corrosion resistance, impact resistance, humidity resistance, thermal resistance, vibration resistance, fire-proof and sound-proof, light weight, workability, and easy to install and transport, while not sacrificing the original strength of its raw materials – aluminum and PE materials.

Parameters:
Specifications Of Aluminum Composite Panel
Normal Width 1220mm,1250mm,1500mm,1570mm, 2000mm
Panel Thickness 2mm 3mm 4mm 5mm 6mm
Aluminum Alloy AA1100,AA3003,AA5005(Other Grade On Requirements)
Aluminum Skin Thickness 0.08mm ~ 0.60mm
Coating PE/PVDF/FEVE/NANO/Anti-scratch/Mill
PE Core Recycle PE Core/Fireproof PE Core/Unbreakable PE Core
Color Solid/ Glossy/Matt/Metallic/Marble/Wooden/Brush/Mirror/Embossed
Length 5800mm in maximum for 20ft container
Delivery 15 to 20 days after order confirmed and receiving deposit
MOQ 600 to 1000 m2 per color
Brand/OEM ALUWEDO®/ Customized
Payment Terms T/T/ L/C at sight/Western Union
Packing By bulk; In Wooden Package
Surface Properties:
Paint Thickness (micron) 20
Pencil Hardness >HB
Toughness of Coating 3T
Temperature Resistance -50˚C to +90˚C
Impact Strength (kg cm2) 50
Boiling Water Resistance Boiling for 2hrs without change
Acid Resistance Immerse Surface in 2% HC1 for 24hrs without change
Alkali Resistance Immersed surface in 2% NaOH for 24hrs without change
Oil Resistance Immerse Surface in 20# engine oil for 24hrs without change
Solvent Resistance Cleaned 100 times with Dimethylbenzene without change
Cleaning Resistance >1000 times without change
Peel Strength 180˚ >5 Newton / mm
Testing Item Standard Result
Unit Weight ASTM D792 T 3mm=4kg/m2
Thermal Expansion ASTM D696 24-28
Thermal Deformation Temperature ASTM D648 115 ℃
Thermal Conduction ASTM D976 0.102kcal/m.hr ℃
Flexural Rigidity ASTM D393 14.0*10^5
Impact Resistance ASTM D732 1.64kgf
Adhesive Strength ASTM D903 0.77kg/mm
Flexural Elasticity ASTM D790 4030kg/mm2
Shear Resistance ASTM D732 2.7kgf/mm2
Fire Propagation ASTM E84 Qualified
Wind-Pressure Resistant ASTM E330 Passed
Properties Against Water ASTM E331 Passed

Description
Aluminum panel of our glossy PE coated ACP undergoes a comprehensive series of processing procedures in coating line, like, being painted with pre-mixed glossy paints, air-drying and etc.

After that, lamination will be addressed towards low density polyethylene, polymeric membrane and coated aluminum panels for final shaping. Since the aluminum composite panel is made with a glossy effect, it will be more attractive when sun shines on it.

Aluwedo is a reliable glossy PE coating aluminum composite panel manufacturer and supplier, offers a wide range of interior and exterior decorative ACP panels for customers. Our aluminum composite panels can be used as architectural wall cladding, building façade, advertising signage, commercial entryway, etc. From the raw material selection, panel manufacturing and surface coating, each step is under strict control, we are sure to offer quality PE coated ACP composite panels with competitive prices.
