PE/PA Microporous Filter

Request a Quote

View All: http://wydryingfiltration.com/2-1-pe-pa-microporous-filter.html

Series XKA

Weiying XKA series PE/PA microporous filter is solid-liquid separation equipment that can be an effective alternative to conventional separation systems such as filter presses, centrifuges and leaf filters. These PE/PA microporous filters are an essential part for fine chemical, pharmaceutical and food industries requiring batch production with high demands of dry filter cakes.

Features

The PE/PA microporous filter features a specially designed structure that helps achieve precision filtration of liquids containing high content of solids, without residue;
Able to catch particles with size greater than 0.3μm at one time;
PE or PA high molecular microporous tube, titanium/ ceramic filter elements;
The filter cake attached on the filter elements is separated and discharged by back blowing. Then, the next filtration cycle begins;
The filtration process is carried out in an airtight enclosure, ensuring safe production while preventing any odors from escaping;
Pneumatic / hydraulic system is adopted for quick opening and closing, enabling the cleaning and maintenance easier and faster;
The corrosion-resistant lining makes the PE/PA microporous filter suitable for handling acidic materials;
Additional insulation jacket can be provided to adapt to the actual application needs;
Fully automatic control;

Technical Data

Model	XKA-1	XKA-2	XKA-3	XKA-5	XKA-10	XKA-20	XKA-30	XKA-40	XKA-60	XKA-100
Filter area (㎡)	1	2	3	5	10	20	30	40	60	100
Handling capacity (T/h)			Depending on specific experimental data
Working pressure (MPa)	≤0.2
Working temperature (°C)	≤110
Filter body diameter (mm)	300	300	400	550	800	900	1200 1000	1400 1200	1800 1200	2000
Filter body height (mm)	1730	2030	2500	2524	3045	3440	3476	3615	4254	5322
Inlet/outlet diameter (mm)	DN40/ DN40	DN40/ DN40	DN40/ DN40	DN40/ DN50	DN50/ DN65	DN65/ DN65	DN50/ DN65	DN65/ DN65	DN65/ DN65	DN80/ DN80
Cake discharge opening (mm)	300	300	400	550	800	800	1000 800	1200 1000 800	1400 1200 1000 800	1400 1200 1000
Filter tube spacing (mm)	85	50	S5	65	50	50	50	60	55	60
Filter volume (m³)	0.07	0.08	0.12	0.321	0.868	1.25	1.821	1.9	4.8	6.3
Max. cake volume (m³)	0.005	0.01	0.015	0.025	0.05	0.1	0.15	0.2	0.3	0.5
Weight (kg)	280	290	365	580	1000	1270	1950	2279	3800	4750

Weiying is a company dedicated to providing custom engineered filtration and drying equipment for the pharmaceutical, chemical, fine chemical and food industries.
